Ferrari 812 CompetizioneA — [VEHICLE TRIM] - E.25 - WINDSCREEN (diagram 0124)
Exploded view of the [vehicle trim] - e.25 - windscreen on the Ferrari 812 CompetizioneA, with 26 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 CompetizioneA [VEHICLE TRIM] - E.25 - WINDSCREEN exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizionea/0124.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 799798 | Ferrari Compl. Windscreen - 799798 | Superseded | Order 985799798 instead |
| 1 | 799801 | Ferrari Compl. Windscreen - 799801 | $8,367.75 | Contact us to order |
| 1 | 985799798 | Ferrari Compl. Windscreen - 985799798 | $9,926.82 | Contact us to order |
| 1 | 985799801 | Ferrari Compl. Windscreen - 985799801 | $8,398.98 | Contact us to order |
| 2 | 827638 | Ferrari Compl. RH Underwindscreen Tr - 827638 | $159.79 | Special order, ships in 7-14 days |
| 2 | 845771 | Ferrari Compl. RH Underwindscreen Tr - 845771 | $737.61 | Special order, ships in 7-14 days |
| 3 | 827639 | Ferrari Compl. LH Underwindscreen Tr - 827639 | $159.79 | Special order, ships in 7-14 days |
| 3 | 845772 | Ferrari Compl. LH Underwindscreen Tr - 845772 | $737.61 | Special order, ships in 7-14 days |
| 4 | 68119800 | Ferrari Plate For Screw - 68119800 | $3.03 | Available, ships in 3-6 days |
| 5 | 256490 | Ferrari Screw TBEI M5 x 16 - 256490 | $3.91 | Available, ships in 3-6 days |
| 6 | 89378400 | Ferrari RH A-Pillar Seal - 89378400 | $240.39 | Special order, ships in 7-14 days |
| 7 | 89378300 | Ferrari LH A-Pillar Seal - 89378300 | $240.39 | Special order, ships in 7-14 days |
| 8 | 826445 | Ferrari RH Underwindscreen Seal - 826445 | $107.06 | Special order, ships in 7-14 days |
| 9 | 826456 | Ferrari LH Underwindscreen Seal - 826456 | $107.06 | Special order, ships in 7-14 days |
| 10 | 14215480 | Ferrari Plastic Screw Block D4 - 14215480 | $0.46 | Available, ships in 3-6 days |
| 11 | 15958077 | Ferrari Screw - 15958077 | $6.75 | Special order, ships in 7-14 days |
| 12 | 84434900 | Ferrari Fastener Cover Cap LHD - 84434900 | $4.77 | Available, ships in 3-6 days |
| 13 | 61148700 | Ferrari WASHER - 61148700 | Superseded | Order 12643724 instead |
| 13 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 14 | 16285127 | Ferrari Screw M5 x 16 - 16285127 | $1.05 | Special order, ships in 7-14 days |
| 15 | 88077500 | Ferrari Underwindscreen Tray Seal - 88077500 | $190.11 | Special order, ships in 7-14 days |
| 16 | 178053 | Ferrari Clip - 178053 | $2.64 | In stock |
| 16 | 296779 | Ferrari Hose Clamp 20 to 32mm - 296779 | Superseded | Order 178053 instead |
| 17 | 83364200 | Ferrari Water Drain Pipe LHD - 83364200 | $7.34 | Special order, ships in 7-14 days |
| 18 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 19 | 206739 | Ferrari Tear Clip - 206739 | $16.37 | Available, ships in 3-6 days |
