Ferrari 812 CompetizioneA — [VEHICLE TRIM] - E.36 - REAR LID TRIM (diagram 0137)
Exploded view of the [vehicle trim] - e.36 - rear lid trim on the Ferrari 812 CompetizioneA, with 35 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 CompetizioneA [VEHICLE TRIM] - E.36 - REAR LID TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizionea/0137.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 63402800 | Ferrari Ball Pin - 63402800 | Superseded | Order 85216400 instead | |
| 69205900 | Ferrari Ball Pin - 69205900 | Superseded | Order 85216400 instead | |
| 907509 | Ferrari Compl. Lock Striker - 907509 | Superseded | Order 840355 instead | |
| 64577200 | Ferrari Pin - 64577200 | Superseded | Order 85216400 instead | |
| 65939900 | Ferrari Pin - 65939900 | Superseded | Order 85216400 instead | |
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 12643707 | Ferrari Washer - 12643707 | Superseded | Order 12643778 instead | |
| 12643777 | Ferrari Washer - 12643777 | Superseded | Order 12643778 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead | |
| 1 | 70008084 | Ferrari COMPL. TAILGATE TRIM - 70008084 | Price on request | Contact us for price and availability |
| 1 | 822440 | Ferrari Compl. Tailgate Trim - 822440 | $14,134.65 | Contact us to order |
| 1 | 822442 | Ferrari Compl. Tailgate Trim - 822442 | $14,645.14 | Contact us to order |
| 2 | 889684 | Ferrari Rear Lid Gas Strut - 889684 | $80.84 | Special order, ships in 7-14 days |
| 3 | 85216400 | Ferrari Pin - 85216400 | $2.98 | In stock |
| 4 | 985902212 | Ferrari Cover Terzo Stop Smont. Cs. - 985902212 | $6,198.54 | Special order, ships in 7-14 days |
| 5 | 877360 | Ferrari Compl. Third Brake Light - 877360 | $568.23 | Special order, ships in 7-14 days |
| 6 | 62764200 | Ferrari Spire Clip - 62764200 | $0.82 | Available, ships in 3-6 days |
| 7 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 8 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 8 | 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days |
| 9 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 10 | 13046014 | Ferrari Nut - 13046014 | $0.63 | Special order, ships in 7-14 days |
| 11 | 840355 | Ferrari Compl. Lock Striker - 840355 | $90.95 | Special order, ships in 7-14 days |
| 12 | 16286024 | Ferrari SCREW - 16286024 | $0.38 | Available, ships in 3-6 days |
| 14 | 849815 | Ferrari Anti Vibration Damper - 849815 | $51.62 | Available, ships in 3-6 days |
| 15 | 905900 | Ferrari Rear Rubber Plug - 905900 | $49.14 | Special order, ships in 7-14 days |
| 16 | 747090 | Ferrari Nut - 747090 | $30.57 | Special order, ships in 7-14 days |
| 17 | 899605 | Ferrari Front Rubber Plug - 899605 | $49.14 | Special order, ships in 7-14 days |
| 18 | 14453389 | Ferrari Seal D. 15.60 x 1 - 14453389 | $4.77 | Available, ships in 3-6 days |
| 19 | 13046114 | Ferrari Flanged Nut - 13046114 | $0.31 | Available, ships in 3-6 days |
| 20 | 12643778 | Ferrari Washer 6-18 x 1.5 - 12643778 | $0.54 | Available, ships in 3-6 days |
| 21 | 747092 | Ferrari Nut - 747092 | $32.76 | Special order, ships in 7-14 days |
| 22 | 66092400 | Ferrari Trim Clip - 66092400 | $0.25 | In stock |
| 23 | 82672700 | Ferrari Fixing Clip - 82672700 | $1.67 | Available, ships in 3-6 days |
