Ferrari 812 CompetizioneA — [ELECTRICAL SYSTEM] - F.09 - LIGHTING SYSTEMS (diagram 0184)
Exploded view of the [electrical system] - f.09 - lighting systems on the Ferrari 812 CompetizioneA, with 40 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 CompetizioneA [ELECTRICAL SYSTEM] - F.09 - LIGHTING SYSTEMS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizionea/0184.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 62767600 | Ferrari Clip For Screw - 62767600 | Superseded | Order 83851800 instead | |
| 14371274 | Ferrari Clip For Screw M5 - 14371274 | Superseded | Order 83851800 instead | |
| 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 325610 | Ferrari RH Headlamp - 325610 | $4,645.96 | Special order, ships in 7-14 days |
| 1 | 336571 | Ferrari RH Headlamp - 336571 | $5,472.34 | Special order, ships in 7-14 days |
| 1 | 336577 | Ferrari RH Headlamp - 336577 | $4,760.45 | Special order, ships in 7-14 days |
| 1 | 336583 | Ferrari RH Headlamp - 336583 | $5,511.88 | Special order, ships in 7-14 days |
| 1 | 338309 | Ferrari RH Headlamp - 338309 | $4,747.97 | Special order, ships in 7-14 days |
| 1 | 338313 | Ferrari RH Headlamp - 338313 | $5,511.88 | Special order, ships in 7-14 days |
| 2 | 325609 | Ferrari LH Headlamp - 325609 | $4,645.96 | Special order, ships in 7-14 days |
| 2 | 336569 | Ferrari LH Headlamp - 336569 | $5,670.08 | Special order, ships in 7-14 days |
| 2 | 336575 | Ferrari LH Headlamp - 336575 | $4,760.45 | Special order, ships in 7-14 days |
| 2 | 336579 | Ferrari LH Headlamp - 336579 | $5,511.88 | Special order, ships in 7-14 days |
| 2 | 338311 | Ferrari LH Headlamp - 338311 | $4,747.97 | Special order, ships in 7-14 days |
| 2 | 338315 | Ferrari LH Headlamp - 338315 | $5,511.88 | Special order, ships in 7-14 days |
| 3 | 10903287 | Ferrari Screw - 10903287 | $1.48 | Special order, ships in 7-14 days |
| 4 | 12647678 | Ferrari Washer D1 6.15- - 12647678 | $0.84 | Special order, ships in 7-14 days |
| 5 | 806191 | Ferrari RH Tail Light Carrier - 806191 | $174.82 | Special order, ships in 7-14 days |
| 6 | 806193 | Ferrari LH Tail Light Carrier - 806193 | $174.82 | Special order, ships in 7-14 days |
| 7 | 322257 | Ferrari Inner RH Taillight - 322257 | $1,223.91 | Special order, ships in 7-14 days |
| 8 | 322258 | Ferrari Inner LH Tail Light - 322258 | $1,223.91 | Special order, ships in 7-14 days |
| 9 | 317207 | Ferrari Outer RH Taillight - 317207 | $1,223.91 | Special order, ships in 7-14 days |
| 9 | 325107 | Ferrari Outer RH Taillight - 325107 | $1,202.06 | Special order, ships in 7-14 days |
| 10 | 317208 | Ferrari Outer LH Taillight - 317208 | $1,223.91 | Special order, ships in 7-14 days |
| 10 | 325108 | Ferrari Outer LH Taillight - 325108 | $1,202.06 | Available, ships in 3-6 days |
| 11 | 834535 | Ferrari Compl. RH Taillight Surround - 834535 | $368.79 | Special order, ships in 7-14 days |
| 12 | 834543 | Ferrari Compl. LH Taillight Surround - 834543 | $368.79 | Special order, ships in 7-14 days |
| 13 | 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days |
| 14 | 86495500 | Ferrari Screw M6 x 40 Torx T30 TBTX - 86495500 | $0.86 | Available, ships in 3-6 days |
| 15 | 68040000 | Ferrari Washer 6X20x2 - 68040000 | $0.27 | Available, ships in 3-6 days |
| 16 | 86276300 | Ferrari SCREW - 86276300 | $7.84 | Special order, ships in 7-14 days |
| 17 | 66927700 | Ferrari Bracket with Collar - 66927700 | $1.99 | Available, ships in 3-6 days |
| 17 | 83851800 | Ferrari Clip For Screw M5 - 83851800 | $1.69 | Available, ships in 3-6 days |
| 18 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 19 | 869390 | Ferrari Front Light Unit - 869390 | $2,566.51 | Special order, ships in 7-14 days |
| 19 | 869388 | Ferrari Front Light Unit. Base Versi - 869388 | $1,920.19 | Special order, ships in 7-14 days |
| 20 | 318013 | Ferrari Light Unit - 318013 | $61.45 | Special order, ships in 7-14 days |
| 21 | 317211 | Ferrari Lateral Turn Indicator - 317211 | $159.79 | Special order, ships in 7-14 days |
| 22 | 14447078 | Ferrari Washer D. 5.5 - 15 x 1 - 14447078 | $0.54 | Special order, ships in 7-14 days |
