Ferrari 812 CompetizioneA — [ELECTRICAL SYSTEM] - F.12 - DCT GEARBOX SYSTEM (diagram 0187)
Exploded view of the [electrical system] - f.12 - dct gearbox system on the Ferrari 812 CompetizioneA, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari 812 CompetizioneA [ELECTRICAL SYSTEM] - F.12 - DCT GEARBOX SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/812-competizionea/0187.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 1 | 831778 | Ferrari Dct Gearbox Ecu - 831778 | $2,510.30 | Special order, ships in 7-14 days |
| 2 | 343072 | Ferrari Dct Wiring Harness - 343072 | $1,131.03 | Special order, ships in 7-14 days |
| 3 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 3 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 4 | 942830 | Ferrari Compl. Bridge - 942830 | $2,938.85 | Special order, ships in 7-14 days |
| 4 | 942831 | Ferrari Compl. Bridge - 942831 | $3,756.10 | Special order, ships in 7-14 days |
| 4 | 952357 | Ferrari Compl. Bridge - 952357 | $2,685.94 | Special order, ships in 7-14 days |
| 4 | 952378 | Ferrari Compl. Bridge - 952378 | $2,908.40 | Special order, ships in 7-14 days |
| 4 | 996387 | Ferrari Compl. Bridge - 996387 | $3,824.02 | Special order, ships in 7-14 days |
