Ferrari 812 GTS — GEARBOX REPAIR KIT (diagram 0025)
Exploded view of the gearbox repair kit on the Ferrari 812 GTS, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 70004248 | Ferrari Turbo 1.1 Kit - 70004248 | $648.83 | Special order, ships in 7-14 days |
| 2 | 70004185 | Ferrari SL 1.4 Gear Service Kit - 70004185 | $1,609.14 | Special order, ships in 7-14 days |
| 3 | 70004190 | Ferrari SL 1.6 Gear Service Kit - 70004190 | $2,175.18 | Special order, ships in 7-14 days |
| 4 | 70004243 | Ferrari SAP Kit - 70004243 | $11,535.98 | Special order, ships in 7-14 days |
| 5 | 70004249 | Ferrari CCP Kit - 70004249 | $29,063.29 | Special order, ships in 7-14 days |
| 6 | 70004092 | Ferrari Differential Gear - 70004092 | $5,314.41 | Special order, ships in 7-14 days |
| 7 | 70005184 | Ferrari Gearbox Speed Sensor Kit Level 3 - 70005184 | $6,819.74 | Special order, ships in 7-14 days |
| 8 | 70005183 | Ferrari Gearbox Temperature Sensor - 70005183 | $4,859.59 | Special order, ships in 7-14 days |
