Ferrari Daytona SP3 — [ENGINE] - B.05 - PISTONS AND CONNECTING RODS (diagram 0008)
Exploded view of the [engine] - b.05 - pistons and connecting rods on the Ferrari Daytona SP3, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [ENGINE] - B.05 - PISTONS AND CONNECTING RODS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0008.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 805669 | Ferrari Compl. Connecting Rod And Ca - 805669 | $1,790.82 | Special order, ships in 7-14 days |
| 2 | 912359 | Ferrari Bush - 912359 | $71.28 | Special order, ships in 7-14 days |
| 3 | 767760 | Ferrari SCREW - 767760 | $71.28 | Special order, ships in 7-14 days |
| 4 | 337553 | Ferrari Alignment Pin - 337553 | $10.81 | Special order, ships in 7-14 days |
| 5 | 811361 | Ferrari Compl. RH Cyl. Bank Piston - 811361 | $1,180.21 | Special order, ships in 7-14 days |
| 6 | 811362 | Ferrari Compl. LH Cyl. Bank Piston - 811362 | $1,180.21 | Special order, ships in 7-14 days |
| 7 | 304680 | Ferrari Con Rod Half-Bearing - 304680 | $31.93 | Special order, ships in 7-14 days |
| 7 | 304681 | Ferrari Connecting Rod Half-Bearing - 304681 | $34.40 | Special order, ships in 7-14 days |
| 7 | 304682 | Ferrari Connecting Rod Half-Bearing - 304682 | $34.40 | Special order, ships in 7-14 days |
| 7 | 823846 | Ferrari Connecting Rod Half-Bearing - 823846 | $31.93 | Special order, ships in 7-14 days |
| 7 | 910540 | Ferrari Connecting Rod Half-Bearing - 910540 | $34.40 | Special order, ships in 7-14 days |
| 8 | 971484 | Ferrari COMPL. PISTON RING SET - 971484 | Price on request | Contact us for price and availability |
