Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.08.01 - EXHAUST SYSTEM - FRONT SECTION (diagram 0056)

Exploded view of the [mechanical system] - d.08.01 - exhaust system - front section on the Ferrari Daytona SP3, with 14 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.08.01 - EXHAUST SYSTEM - FRONT SECTION exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
1888428Ferrari Compl. RH Gpf Cat - 888428$38,320.60Contact us to order
2888431Ferrari Compl. LH Gpf Cat - 888431$38,242.51Contact us to order
3275465Ferrari Gasket - 275465$103.25Available, ships in 3-6 days
4290743Ferrari V-Clamp For Fastening Catalytic Converter to Manifold - 290743$164.72Special order, ships in 7-14 days
5292945Ferrari Nut M8 x 1.25 - 292945$28.39Special order, ships in 7-14 days
6292946Ferrari 812/F12 Exhaust Clamp Shim/Spacer - 292946$9.75In stock
7767084Ferrari Compl. RH Upper Bracket - 767084$140.13Special order, ships in 7-14 days
8767085Ferrari Compl. LH Upper Bracket - 767085$140.13Special order, ships in 7-14 days
9934525Ferrari Threaded Pin - 934525$12.02Special order, ships in 7-14 days
1014302824Ferrari Allen Screw 8x18 - 14302824$0.46Available, ships in 3-6 days
1111193874Ferrari Washer D.8.4-16x1.4 - 11193874$0.12Available, ships in 3-6 days
12808840Ferrari RH AXLe Shaft Heat Shield - 808840$236.02Special order, ships in 7-14 days
13808839Ferrari LH AXLe Shaft Heat Shield - 808839$236.02Special order, ships in 7-14 days
1416296934Ferrari Screw 6x14 - 16296934$0.90Special order, ships in 7-14 days

All Daytona SP3 diagrams
