Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.08.02 - EXHAUST SYSTEM - REAR SECTION (diagram 0057)
Exploded view of the [mechanical system] - d.08.02 - exhaust system - rear section on the Ferrari Daytona SP3, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.08.02 - EXHAUST SYSTEM - REAR SECTION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0057.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 15896214 | Ferrari Nut M6 x 5 - 15896214 | Superseded | Order 14039614 instead | |
| 1 | 920495 | Ferrari Compl. Rear RH Silencer - 920495 | $9,568.80 | Special order, ships in 7-14 days |
| 2 | 920500 | Ferrari Compl. Rear LH Silencer - 920500 | $9,568.80 | Special order, ships in 7-14 days |
| 3 | 239798 | Ferrari Rubber Exhaust Mount - 239798 | $112.88 | In stock |
| 4 | 874864 | Ferrari RH Silencer Bracket - 874864 | $78.66 | Special order, ships in 7-14 days |
| 5 | 874866 | Ferrari LH Silencer Bracket - 874866 | $78.66 | Special order, ships in 7-14 days |
| 6 | 874784 | Ferrari RH Lateral Bracket - 874784 | $162.25 | Special order, ships in 7-14 days |
| 7 | 874808 | Ferrari LH Lateral Bracket - 874808 | $162.25 | Special order, ships in 7-14 days |
| 8 | 240598 | Ferrari Bracket Plate - 240598 | $21.60 | Available, ships in 3-6 days |
| 9 | 250222 | Ferrari Screw Squared Head 6x18.5 - 250222 | $5.44 | Special order, ships in 7-14 days |
| 10 | 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days |
| 11 | 793030 | Ferrari Silence Bracket - 793030 | $39.31 | Special order, ships in 7-14 days |
| 12 | 801837 | Ferrari Silence Bracket - 801837 | $39.31 | Special order, ships in 7-14 days |
| 13 | 859831 | Ferrari Compl. RH Gearbox Heat Shiel - 859831 | $1,303.14 | Special order, ships in 7-14 days |
| 14 | 859832 | Ferrari Compl. LH Gearbox Heat Shiel - 859832 | $1,303.14 | Special order, ships in 7-14 days |
| 15 | 14040611 | Ferrari Nut M6 - 14040611 | $0.57 | Available, ships in 3-6 days |
