Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.18 - LIFTING THE VEHICLE (diagram 0067)
Exploded view of the [mechanical system] - d.18 - lifting the vehicle on the Ferrari Daytona SP3, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.18 - LIFTING THE VEHICLE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0067.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 284736 | Ferrari Electric Pump - 284736 | Superseded | Order 844230 instead | |
| 255049 | Ferrari Screw 10x1.5x32 - 255049 | Superseded | Order 304224 instead | |
| 1 | 844230 | Ferrari Electric Pump - 844230 | $6,158.72 | Special order, ships in 7-14 days |
| 2 | 285319 | Ferrari Insulation - 285319 | $233.56 | Special order, ships in 7-14 days |
| 3 | 264740 | Ferrari Plug 40x24mm - 264740 | $1.53 | Special order, ships in 7-14 days |
| 4 | 300756 | Ferrari Lift Pump Mounting Bracket - 300756 | $164.72 | Special order, ships in 7-14 days |
| 5 | 304224 | Ferrari Screw 10x1.5x28 - 304224 | $30.57 | Special order, ships in 7-14 days |
| 6 | 255047 | Ferrari Grommet - 255047 | $7.40 | Available, ships in 3-6 days |
| 7 | 255048 | Ferrari Grommet Shim - 255048 | $5.65 | Special order, ships in 7-14 days |
| 8 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 9 | 766923 | Ferrari Lift System Pipe From Pump T - 766923 | $95.87 | Special order, ships in 7-14 days |
| 10 | 254931 | Ferrari Adapter Socket - 254931 | $12.71 | Special order, ships in 7-14 days |
| 11 | 291408 | Ferrari Clip - 291408 | $0.34 | Special order, ships in 7-14 days |
| 12 | 895551 | Ferrari Underbody Lift System Pipe - 895551 | $181.93 | Special order, ships in 7-14 days |
| 13 | 249650 | Ferrari Clip 4.7X1 - 249650 | $0.82 | Available, ships in 3-6 days |
| 14 | 333410 | Ferrari Lift System Pipe From Block - 333410 | $83.57 | Special order, ships in 7-14 days |
| 15 | 296025 | Ferrari Lift System Pipe From Block To LH Front Wheel - 296025 | $63.90 | Special order, ships in 7-14 days |
| 16 | 292189 | Ferrari Lift System Distributor Block - 292189 | $169.62 | Special order, ships in 7-14 days |
| 17 | 262737 | Ferrari Rubber Retainer - 262737 | $10.06 | Special order, ships in 7-14 days |
| 18 | 116374 | Ferrari/Maserati Clip - 116374 | $3.20 | In stock |
