Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.19 - ACCELERATOR CONTROL (diagram 0068)
Exploded view of the [mechanical system] - d.19 - accelerator control on the Ferrari Daytona SP3, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.19 - ACCELERATOR CONTROL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0068.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 283408 | Ferrari Accelerator Pedal Complete - 283408 | $663.86 | Special order, ships in 7-14 days |
| 2 | 283409 | Ferrari Pedal Cover - 283409 | $216.35 | Special order, ships in 7-14 days |
| 3 | 14305224 | Ferrari Screw 6x16 - 14305224 | $0.96 | Available, ships in 3-6 days |
| 3 | 14305221 | Ferrari Screw M6 x 16 - 14305221 | $0.17 | Available, ships in 3-6 days |
| 4 | 12646624 | Ferrari Washer 6.15-15x1.5 - 12646624 | $0.40 | Available, ships in 3-6 days |
