Ferrari Daytona SP3 — [MECHANICAL SYSTEM] - D.27.03 - REAR SUSPENSION - CALIPERS AND DISCS (diagram 0081)
Exploded view of the [mechanical system] - d.27.03 - rear suspension - calipers and discs on the Ferrari Daytona SP3, with 67 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [MECHANICAL SYSTEM] - D.27.03 - REAR SUSPENSION - CALIPERS AND DISCS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0081.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12486580 | Ferrari Botton - 12486580 | Superseded | Order 204781 instead | |
| 116373 | Ferrari Brake Hose - 977802 | Superseded | Order 977802 instead | |
| 175871 | Ferrari Clip - 175871 | Superseded | Order 204781 instead | |
| 323365 | Ferrari Connector Fastener Clip - 323365 | Superseded | Order 204781 instead | |
| 271711 | Ferrari Front Flexible Tube 330mm - 271711 | Superseded | Order 977802 instead | |
| 948578 | Ferrari Pipe - 948578 | $194.48 | Special order, ships in 7-14 days | |
| 240969 | Ferrari RH Disc Shield - 240969 | Superseded | Order 257424 instead | |
| 190870 | Ferrari Screw 6x14 - 190870 | $4.10 | Special order, ships in 7-14 days | |
| 1 | 952684 | Ferrari LH Rear Caliper With Pads - 952684 | $8,351.10 | Special order, ships in 7-14 days |
| 1 | 952688 | Ferrari LH Rear Caliper With Pads - 952688 | $8,817.36 | Special order, ships in 7-14 days |
| 1 | 952691 | Ferrari LH Rear Caliper With Pads - 952691 | $9,375.22 | Special order, ships in 7-14 days |
| 1 | 952703 | Ferrari LH Rear Caliper With Pads - 952703 | $8,817.36 | Special order, ships in 7-14 days |
| 1 | 952710 | Ferrari LH Rear Caliper With Pads - 952710 | $9,375.22 | Special order, ships in 7-14 days |
| 1 | 952711 | Ferrari LH Rear Caliper With Pads - 952711 | $8,817.36 | Special order, ships in 7-14 days |
| 1 | 952712 | Ferrari LH Rear Caliper With Pads - 952712 | $8,817.36 | Special order, ships in 7-14 days |
| 1 | 952713 | Ferrari LH Rear Caliper With Pads - 952713 | $8,638.34 | Special order, ships in 7-14 days |
| 1 | 952714 | Ferrari LH Rear Caliper With Pads - 952714 | $8,505.13 | Special order, ships in 7-14 days |
| 1 | 873286 | Ferrari Rear LH Calliper With Pads - 873286 | $8,342.78 | Special order, ships in 7-14 days |
| 1 | 879831 | Ferrari Rear LH Calliper With Pads - 879831 | $8,494.72 | Special order, ships in 7-14 days |
| 1 | 879832 | Ferrari Rear LH Calliper With Pads - 879832 | $8,813.20 | Special order, ships in 7-14 days |
| 1 | 879833 | Ferrari Rear LH Calliper With Pads - 879833 | $8,813.20 | Special order, ships in 7-14 days |
| 1 | 879834 | Ferrari Rear LH Calliper With Pads - 879834 | $9,375.22 | Special order, ships in 7-14 days |
| 1 | 879835 | Ferrari Rear LH Calliper With Pads - 879835 | $9,375.22 | Special order, ships in 7-14 days |
| 1 | 879836 | Ferrari Rear LH Calliper With Pads - 879836 | $8,813.20 | Special order, ships in 7-14 days |
| 1 | 879837 | Ferrari Rear LH Calliper With Pads - 879837 | $8,630.02 | Special order, ships in 7-14 days |
| 1 | 879838 | Ferrari Rear LH Calliper With Pads - 879838 | $8,813.20 | Special order, ships in 7-14 days |
| 1 | 873290 | Ferrari Rear RH Calliper With Pads - 873290 | $8,342.78 | Special order, ships in 7-14 days |
| 1 | 879839 | Ferrari Rear RH Calliper With Pads - 879839 | $8,494.72 | Special order, ships in 7-14 days |
| 1 | 879840 | Ferrari Rear RH Calliper With Pads - 879840 | $8,813.20 | Special order, ships in 7-14 days |
| 1 | 879841 | Ferrari Rear RH Calliper With Pads - 879841 | $8,813.20 | Special order, ships in 7-14 days |
| 1 | 879842 | Ferrari Rear RH Calliper With Pads - 879842 | $9,375.22 | Special order, ships in 7-14 days |
| 1 | 879843 | Ferrari Rear RH Calliper With Pads - 879843 | $9,375.22 | Special order, ships in 7-14 days |
| 1 | 879844 | Ferrari Rear RH Calliper With Pads - 879844 | $8,813.20 | Special order, ships in 7-14 days |
| 1 | 879845 | Ferrari Rear RH Calliper With Pads - 879845 | $8,630.02 | Special order, ships in 7-14 days |
| 1 | 879846 | Ferrari Rear RH Calliper With Pads - 879846 | $8,813.20 | Special order, ships in 7-14 days |
| 1 | 952686 | Ferrari RH Rear Caliper With Pads - 952686 | $8,351.10 | Special order, ships in 7-14 days |
| 1 | 952715 | Ferrari RH Rear Caliper With Pads - 952715 | $8,817.36 | Special order, ships in 7-14 days |
| 1 | 952716 | Ferrari RH Rear Caliper With Pads - 952716 | $9,375.22 | Special order, ships in 7-14 days |
| 1 | 952718 | Ferrari RH Rear Caliper With Pads - 952718 | $8,817.36 | Special order, ships in 7-14 days |
| 1 | 952719 | Ferrari RH Rear Caliper With Pads - 952719 | $9,375.22 | Special order, ships in 7-14 days |
| 1 | 952720 | Ferrari RH Rear Caliper With Pads - 952720 | $8,817.36 | Special order, ships in 7-14 days |
| 1 | 952721 | Ferrari RH Rear Caliper With Pads - 952721 | $8,817.36 | Special order, ships in 7-14 days |
| 1 | 952724 | Ferrari RH Rear Caliper With Pads - 952724 | $8,638.34 | Special order, ships in 7-14 days |
| 1 | 952726 | Ferrari RH Rear Caliper With Pads - 952726 | $8,505.13 | Special order, ships in 7-14 days |
| 2 | 768172 | Ferrari Brake Disc - 768172 | $9,627.73 | Special order, ships in 7-14 days |
| 3 | 257424 | Ferrari RH Rear Disc Shield - 257424 | $95.87 | Special order, ships in 7-14 days |
| 4 | 228131 | Ferrari Screw M8 x 20 - 228131 | $1.53 | Available, ships in 3-6 days |
| 5 | 228132 | Ferrari Spring Washer - 228132 | $0.59 | Available, ships in 3-6 days |
| 6 | 250657 | Ferrari Screw M6 x 14 TBTX - 250657 | $13.36 | Available, ships in 3-6 days |
| 7 | 196837 | Ferrari Screw M12 x 1.5 x 105 - 196837 | $33.28 | Available, ships in 3-6 days |
| 8 | 291775 | Ferrari Rear Brake Calliper Spacer - 291775 | $36.86 | Special order, ships in 7-14 days |
| 9 | 296545 | Ferrari Rear Caliper Housing Cover - 296545 | $737.61 | Special order, ships in 7-14 days |
| 10 | 281349 | Ferrari Pipe - 281349 | $194.22 | Special order, ships in 7-14 days |
| 11 | 296782 | Ferrari Hose Clamp 32-50mm - 296782 | $17.67 | Available, ships in 3-6 days |
| 12 | 14305187 | Ferrari Screw 6x12 - 14305187 | $0.77 | Available, ships in 3-6 days |
| 13 | 12648278 | Ferrari Washer 6 15-10X - 12648278 | $0.50 | Available, ships in 3-6 days |
| 14 | 299555 | Ferrari Rear Brake Pipe From Caliper To RH Hose - 299555 | $58.98 | Special order, ships in 7-14 days |
| 15 | 10815787 | Ferrari Clamp - 10815787 | $0.31 | Available, ships in 3-6 days |
| 16 | 116374 | Ferrari/Maserati Clip - 116374 | $3.20 | In stock |
| 17 | 977802 | Ferrari Flexible Brake Hose L 330mm - 977802 | $81.11 | Available, ships in 3-6 days |
| 18 | 204781 | Ferrari Clip - 204781 | $1.67 | Available, ships in 3-6 days |
| 19 | 70003759 | Ferrari 488/F8/F12 Rear Brake Pad Set - 70003759 | $1,757.80 | In stock |
| 19 | 851786 | Ferrari Rear Pad Set With Spring - 851786 | $3,406.15 | Special order, ships in 7-14 days |
| 20 | 70003667 | Ferrari Set Of EPB Pads - 70003667 | $1,968.72 | Available, ships in 3-6 days |
| 21 | 70003493 | Ferrari Rear Brake Caliper Seal Kit - 70003493 | $108.90 | In stock |
| 22 | 215665 | Ferrari Bleed Nipple Valve - 215665 | $78.66 | Available, ships in 3-6 days |
| 23 | 215666 | Ferrari Cap For Bleed Nipple - 215666 | $51.62 | Available, ships in 3-6 days |
