Ferrari Daytona SP3 — [VEHICLE TRIM] - E.15 - CENTRE SHIELDS (diagram 0114)
Exploded view of the [vehicle trim] - e.15 - centre shields on the Ferrari Daytona SP3, with 14 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.15 - CENTRE SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0114.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 290589 | Ferrari Screw 4x8 - 290589 | Superseded | Order 309629 instead | |
| 1 | 88412400 | Ferrari RH Rear Lateral Panel - 88412400 | $5,965.69 | Special order, ships in 7-14 days |
| 2 | 88412500 | Ferrari LH Rear Lateral Panel - 88412500 | $5,965.69 | Special order, ships in 7-14 days |
| 3 | 85824800 | Ferrari Screw - 85824800 | $56.52 | Special order, ships in 7-14 days |
| 4 | 742275 | Ferrari RH Inner Centre Dam - 742275 | $152.62 | Special order, ships in 7-14 days |
| 5 | 742274 | Ferrari LH Inner Centre Dam - 742274 | $152.62 | Special order, ships in 7-14 days |
| 6 | 742273 | Ferrari RH Outer Centre Dam - 742273 | $91.08 | Special order, ships in 7-14 days |
| 7 | 742272 | Ferrari LH Outer Centre Dam - 742272 | $91.08 | Special order, ships in 7-14 days |
| 8 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 9 | 85745200 | Ferrari Plug In Tunnel Cover - 85745200 | $81.23 | Special order, ships in 7-14 days |
| 10 | 295423 | Ferrari Adhesive Foam - 295423 | $1.69 | Special order, ships in 7-14 days |
| 11 | 85077900 | Ferrari Screw - 85077900 | $0.34 | Special order, ships in 7-14 days |
| 12 | 13046014 | Ferrari Nut - 13046014 | $0.63 | Special order, ships in 7-14 days |
| 13 | 309629 | Ferrari Screw 4x8 - 309629 | $4.77 | Special order, ships in 7-14 days |
