Ferrari Daytona SP3 — [VEHICLE TRIM] - E.20 - ENGINE COMPARTMENT INSULATION (diagram 0119)

Exploded view of the [vehicle trim] - e.20 - engine compartment insulation on the Ferrari Daytona SP3, with 44 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [VEHICLE TRIM] - E.20 - ENGINE COMPARTMENT INSULATION exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
302724Ferrari Screw - 302724SupersededOrder 302723 instead
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
12638108Ferrari Washer - 12638108SupersededOrder 12638178 instead
12638177Ferrari Washer - 12638177SupersededOrder 12638178 instead
61276300Ferrari Washer - 61276300SupersededOrder 12638178 instead
1764038Ferrari Rear Soundproofing For Fuel - 764038$1,501.96Special order, ships in 7-14 days
2764567Ferrari Rear Soundproofing - 764567$1,009.51Special order, ships in 7-14 days
3764037Ferrari Central Engine Heat Shield - 764037$5,670.21Special order, ships in 7-14 days
4887679Ferrari RH Heat Shield For Pressed E - 887679$2,204.29Special order, ships in 7-14 days
5897773Ferrari LH Heat Shield For Pressed E - 897773$2,133.94Special order, ships in 7-14 days
6302723Ferrari Ergal Screw 5x15 - 302723$9.39Special order, ships in 7-14 days
7911236Ferrari Compl. RH Upper Front Engine - 911236$3,932.56Special order, ships in 7-14 days
8941234Ferrari Compl. LH Upper Front Engine - 941234$4,136.59Special order, ships in 7-14 days
9911234Ferrari RH Lateral Front Engine Comp - 911234$3,932.56Special order, ships in 7-14 days
10788597Ferrari Compl. LH Lateral Front Engi - 788597$4,228.04Special order, ships in 7-14 days
11788896Ferrari Compl. RH Upper Rear Engine - 788896$6,774.72Contact us to order
11941241Ferrari Compl. RH Upper Rear Engine - 941241SupersededOrder 788896 instead
12788901Ferrari LH Rear Front Engine Compart - 788901$6,774.72Special order, ships in 7-14 days
12948943Ferrari LH Rear Front Engine Compart - 948943SupersededOrder 788901 instead
13763114Ferrari Clip - 763114$13.11Special order, ships in 7-14 days
14969009Ferrari Quarter Turn Screw - 969009$10.04Special order, ships in 7-14 days
15763128Ferrari Fastening For Screw - 763128$3.47Special order, ships in 7-14 days
16949004Ferrari Compl. RH Lateral RH Engine - 949004$9,042.34Special order, ships in 7-14 days
17948975Ferrari Compl. LH Lateral Engine Com - 948975$9,042.34Special order, ships in 7-14 days
18763995Ferrari Rear Engine Compartment Cove - 763995$2,298.08Special order, ships in 7-14 days
19794219Ferrari Engine Compartment Oil Reser - 794219$3,114.15Special order, ships in 7-14 days
19864185Ferrari Engine Compartment Oil Reser - 864185$4,811.95Special order, ships in 7-14 days
20812234Ferrari Rear Fastener Bracket For RH - 812234$61.52Special order, ships in 7-14 days
21763991Ferrari Rear Fastener Bracket For LH - 763991$41.82Special order, ships in 7-14 days
22298365Ferrari Split Washer - 298365$14.62Special order, ships in 7-14 days
2312638178Ferrari Washer 5.45-14x1 - 12638178$0.13Available, ships in 3-6 days
2485692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
25306704Ferrari Front Soundproofing For Fuel - 306704$1,329.59Special order, ships in 7-14 days
2555057229Ferrari Ins. Anteriore Vano Serbatoi - 55057229$984.88Special order, ships in 7-14 days
26763999Ferrari RH Tunnel Heat Shield - 763999$320.06Special order, ships in 7-14 days
27763997Ferrari LH Tunnel Heat Shield - 763997$320.06Special order, ships in 7-14 days
28308416Ferrari Split Washer - 308416$5.88Special order, ships in 7-14 days
2980880700Ferrari Spring Plate - 80880700$0.82Special order, ships in 7-14 days
3067315400Ferrari Washer - 67315400$0.82Special order, ships in 7-14 days
31952992Ferrari LH Node Casting Insulation - 952992$20.41Special order, ships in 7-14 days
31952993Ferrari RH Node Casting Insulation - 952993$20.41Special order, ships in 7-14 days
32952994Ferrari LH Lower Side Member Insulat - 952994$29.52Special order, ships in 7-14 days
32952995Ferrari RH Lower Side Member Insulat - 952995$29.52Special order, ships in 7-14 days

All Daytona SP3 diagrams
