Ferrari Daytona SP3 — [VEHICLE TRIM] - E.34 - FRONT LID LOCK (diagram 0135)
Exploded view of the [vehicle trim] - e.34 - front lid lock on the Ferrari Daytona SP3, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.34 - FRONT LID LOCK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0135.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 750604 | Ferrari Emergency Front Lid Release - 750604 | $78.76 | Special order, ships in 7-14 days |
| 2 | 904729 | Ferrari Compl. Front Lid Lock - 904729 | $4,364.05 | Special order, ships in 7-14 days |
| 3 | 14305324 | Ferrari Screw M6 x 20mm - 14305324 | $0.17 | Available, ships in 3-6 days |
| 4 | 10523424 | Ferrari Washer D 6.15-18x2 - 10523424 | $0.92 | Available, ships in 3-6 days |
| 5 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 6 | 920073 | Ferrari Front Lid Bowden Cable Bracket - 920073 | $44.29 | Special order, ships in 7-14 days |
| 7 | 86061200 | Ferrari Screw - 86061200 | $1.25 | Special order, ships in 7-14 days |
| 8 | 86174900 | Ferrari Washer - 86174900 | $4.35 | Special order, ships in 7-14 days |
| 9 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
| 10 | 920886 | Ferrari Retaining Clip - 920886 | $0.82 | Special order, ships in 7-14 days |
| 11 | 786155 | Ferrari Clip - 786155 | $1.80 | Special order, ships in 7-14 days |
