Ferrari Daytona SP3 — [VEHICLE TRIM] - E.36 - REAR LID TRIM (diagram 0137)

Exploded view of the [vehicle trim] - e.36 - rear lid trim on the Ferrari Daytona SP3, with 63 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [VEHICLE TRIM] - E.36 - REAR LID TRIM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
63402800Ferrari Ball Pin - 63402800SupersededOrder 85216400 instead
69205900Ferrari Ball Pin - 69205900SupersededOrder 85216400 instead
306631Ferrari Clip - 306631$7.59Special order, ships in 7-14 days
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
64577200Ferrari Pin - 64577200SupersededOrder 85216400 instead
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
12638108Ferrari Washer - 12638108SupersededOrder 12638178 instead
12638177Ferrari Washer - 12638177SupersededOrder 12638178 instead
156093Ferrari Washer - 156093SupersededOrder 12646778 instead
61276300Ferrari Washer - 61276300SupersededOrder 12638178 instead
1807570Ferrari Compl. Rear Lid Back Panel - 807570$35,213.27Special order, ships in 7-14 days
1951233Ferrari Compl. Rear Lid Back Panel - 951233$15,914.80Special order, ships in 7-14 days
2918606Ferrari Compl. Rear Lid Lens - 918606$11,852.19Special order, ships in 7-14 days
388004600Ferrari Screw 5x16 - 88004600$3.26Special order, ships in 7-14 days
385833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
4920641Ferrari COMPL. AIR DUCT TO ENGINE - 920641Price on requestContact us for price and availability
5951091Ferrari RH Lateral Cover - 951091$3,156.37Special order, ships in 7-14 days
6951080Ferrari LH Lateral Cover - 951080$3,156.37Special order, ships in 7-14 days
785692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
8951073Ferrari Dorsale Cofano Poster Riv In - 951073$4,677.49Special order, ships in 7-14 days
9747090Ferrari Nut - 747090$30.57Special order, ships in 7-14 days
9113647Ferrari Nyloc Nut - 113647$0.52Available, ships in 3-6 days
1012638178Ferrari Washer 5.45-14x1 - 12638178$0.13Available, ships in 3-6 days
11918600Ferrari Lower Grille Of Back Panel - 918600$262.62Special order, ships in 7-14 days
12918599Ferrari Upper Grille Of Back Panel - 918599$284.51Special order, ships in 7-14 days
1385833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
1412646778Ferrari Washer - 12646778$0.89In stock
1485882600Ferrari Washer - 85882600$0.17Available, ships in 3-6 days
1412644478Ferrari Washer D. 6.45 - 15 x 1 - 12644478SupersededOrder 85882600 instead
15786712Ferrari Compl. Rear View Camera Fast - 786712$199.41Special order, ships in 7-14 days
1686705000Ferrari Screw M5x10 TBFTX - 86705000$1.36Special order, ships in 7-14 days
17918601Ferrari Rear View Camera Mounting Br - 918601$238.82Special order, ships in 7-14 days
18954485Ferrari Rear Lid Stabilus - 954485$152.62Special order, ships in 7-14 days
1965939900Ferrari Pin - 65939900SupersededOrder 85216400 instead
1985216400Ferrari Pin - 85216400$2.98In stock
21745835Ferrari Rear Lid Rollbar Centring Bu - 745835$31.99Special order, ships in 7-14 days
2265708600Ferrari Bush - 65708600$11.54Special order, ships in 7-14 days
2310725977Ferrari Nut - 10725977$16.83Special order, ships in 7-14 days
24793794Ferrari Screw - 793794$14.84Special order, ships in 7-14 days
2585750300Ferrari Locator - 85750300$31.99Special order, ships in 7-14 days
2685835000Ferrari Plug - 85835000$174.80Special order, ships in 7-14 days
2714447078Ferrari Washer D. 5.5 - 15 x 1 - 14447078$0.54Special order, ships in 7-14 days
28856582Ferrari Spacer Block - 856582$125.37Available, ships in 3-6 days
2981429600Ferrari Lock Striker - 81429600$714.03Special order, ships in 7-14 days
3086276300Ferrari SCREW - 86276300$7.84Special order, ships in 7-14 days
31306756Ferrari Clip - 306756$1.59Special order, ships in 7-14 days
32750332Ferrari Compl. RH Lateral Flick - 750332$3,161.06Special order, ships in 7-14 days
32781119Ferrari COMPL. RH LATERAL FLICK - 781119Price on requestContact us for price and availability
32788118Ferrari Compl. RH Lateral Flick - 788118$3,097.73Special order, ships in 7-14 days
32788120Ferrari Compl. RH Lateral Flick - 788120$3,135.27Special order, ships in 7-14 days
32807101Ferrari COMPL. RH LATERAL FLICK - 807101Price on requestContact us for price and availability
33749916Ferrari Compl. LH Lateral Flick - 749916$3,135.27Special order, ships in 7-14 days
33781124Ferrari COMPL. LH LATERAL FLICK - 781124Price on requestContact us for price and availability
33788110Ferrari Compl. LH Lateral Flick - 788110$3,097.73Special order, ships in 7-14 days
33788116Ferrari Compl. LH Lateral Flick - 788116$3,161.06Special order, ships in 7-14 days
33807100Ferrari COMPL. LH LATERAL FLICK - 807100Price on requestContact us for price and availability
3412647600Ferrari Washer - 12647600$0.31Special order, ships in 7-14 days
3412647678Ferrari Washer D1 6.15- - 12647678$0.84Special order, ships in 7-14 days
35256323Ferrari Screw 5x16 - 256323$0.98Available, ships in 3-6 days
36946417Ferrari Dado M25X2 Inox - 946417$2.38Special order, ships in 7-14 days
3713046012Ferrari Nut - 13046012SupersededOrder 13046011 instead
