Ferrari Daytona SP3 — [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS (diagram 0157)
Exploded view of the [vehicle trim] - e.47.09 - dashboard - fasteners on the Ferrari Daytona SP3, with 48 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0157.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 86574400 | Ferrari Screw - 86574400 | Superseded | Order 86876500 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead | |
| 13579001 | Ferrari Washer D.4.15-9X0.5 - 13579001 | Superseded | Order 12642821 instead | |
| 13337547 | Ferrari Washer D.5 - 13337547 | Superseded | Order 12642821 instead | |
| 1 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 2 | 67278400 | Ferrari BRACKET - 67278400 | $21.60 | Special order, ships in 7-14 days |
| 3 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
| 4 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 4 | 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days |
| 5 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 6 | 835458 | Ferrari Raymond Clip - 835458 | $0.82 | Special order, ships in 7-14 days |
| 7 | 65752800 | Ferrari Screw M4 x 10 TBEI - 65752800 | $4.12 | Available, ships in 3-6 days |
| 8 | 68700200 | Ferrari Fixing Clip - 68700200 | $10.68 | Special order, ships in 7-14 days |
| 9 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 10 | 86876500 | Ferrari Screw M4 x 12 TBEI - 86876500 | $7.84 | Special order, ships in 7-14 days |
| 11 | 85691900 | Ferrari Screw M5 x 8 TBFTX - 85691900 | $0.65 | Available, ships in 3-6 days |
| 12 | 13027026 | Ferrari Screw M6 x 16 TCEI - 13027026 | $2.01 | Available, ships in 3-6 days |
| 13 | 14499304 | Ferrari Washer - 14499304 | $1.49 | Special order, ships in 7-14 days |
| 14 | 10902224 | Ferrari Screw M6 x 16 - 10902224 | $0.12 | Available, ships in 3-6 days |
| 15 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
| 16 | 65366700 | Ferrari Screw 5x12 TBEI - 65366700 | $1.74 | Available, ships in 3-6 days |
| 17 | 88004600 | Ferrari Screw 5x16 - 88004600 | $3.26 | Special order, ships in 7-14 days |
| 18 | 231622 | Ferrari Screw M6 x 35 - 231622 | $0.65 | Available, ships in 3-6 days |
| 19 | 86276300 | Ferrari SCREW - 86276300 | $7.84 | Special order, ships in 7-14 days |
| 20 | 894693 | Ferrari Stud - 894693 | $61.52 | Special order, ships in 7-14 days |
| 21 | 11625824 | Ferrari Screw 6x18 - 11625824 | $0.71 | Available, ships in 3-6 days |
| 22 | 85692300 | Ferrari Screw M5 x 20 TBFTX - 85692300 | $0.65 | Available, ships in 3-6 days |
| 23 | 10794011 | Ferrari Nut M4 x 0.7mm - 10794011 | $0.06 | Available, ships in 3-6 days |
| 24 | 12642821 | Ferrari Washer D. 4.15 - 12 x 1.x - 12642821 | $0.82 | Available, ships in 3-6 days |
| 25 | 840526 | Ferrari Stud Bolt - 840526 | $120.62 | Special order, ships in 7-14 days |
| 26 | 14641793 | Ferrari Rivet - 14641793 | Price on request | Contact us for price and availability |
| 28 | 810673 | Ferrari Stud Bolt - 810673 | $56.60 | Special order, ships in 7-14 days |
| 29 | 742353 | Ferrari Stud Bolt - 742353 | $58.98 | Special order, ships in 7-14 days |
| 30 | 894751 | Ferrari Stud Bolt - 894751 | $56.60 | Special order, ships in 7-14 days |
| 31 | 13541334 | Ferrari Stud - 13541334 | $0.98 | Available, ships in 3-6 days |
| 32 | 62764200 | Ferrari Spire Clip - 62764200 | $0.82 | Available, ships in 3-6 days |
| 33 | 81911600 | Ferrari Screw M6 x 22 - 81911600 | $0.98 | Special order, ships in 7-14 days |
| 34 | 88822200 | Ferrari Screw 4 x 10 - 88822200 | $1.30 | Special order, ships in 7-14 days |
| 35 | 14302924 | Ferrari Screw - 14302924 | $0.44 | Available, ships in 3-6 days |
| 36 | 14370774 | Ferrari Small Bracket - 14370774 | $1.59 | Special order, ships in 7-14 days |
| 37 | 16083501 | Ferrari Trim Screw 4x12 - 16083501 | $0.12 | Available, ships in 3-6 days |
| 38 | 61568600 | Ferrari Fixing Plug - 61568600 | $1.65 | Available, ships in 3-6 days |
| 39 | 85833800 | Ferrari Screw M5 x 14 TBFTX - 85833800 | $0.90 | Available, ships in 3-6 days |
| 40 | 301703 | Ferrari Screw - 301703 | $0.71 | Special order, ships in 7-14 days |
