Ferrari Daytona SP3 — [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS (diagram 0167)
Exploded view of the [vehicle trim] - e.55 - wipers and headlamp washers on the Ferrari Daytona SP3, with 29 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0167.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 67190100 | Ferrari Nut - 67190100 | Superseded | Order 194031 instead | |
| 106853 | Ferrari Spring Washer 10mm - 106853 | Superseded | Order 12601474 instead | |
| 10516873 | Ferrari Washer - 10516873 | Superseded | Order 12601474 instead | |
| 12601471 | Ferrari Washer - 12601471 | Superseded | Order 12601474 instead | |
| 1 | 920399 | Ferrari Compl. Windscreen Washer Res - 920399 | $738.64 | Special order, ships in 7-14 days |
| 2 | 920400 | Ferrari COMPL. FILLER PIPE - 920400 | Price on request | Contact us for price and availability |
| 3 | 742043 | Ferrari Windscreen Washer Pipe From - 742043 | $467.80 | Special order, ships in 7-14 days |
| 4 | 742044 | Ferrari Windscreen Washer Pipe From - 742044 | $130.47 | Special order, ships in 7-14 days |
| 5 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 6 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 7 | 86026600 | Ferrari Windscreen Wiper Motor - 86026600 | $2,040.14 | Special order, ships in 7-14 days |
| 8 | 86026500 | Ferrari Windscreen Wiper Arm - 86026500 | $467.80 | Special order, ships in 7-14 days |
| 9 | 84559700 | Ferrari Wiper Blade - 84559700 | $284.51 | Special order, ships in 7-14 days |
| 10 | 12601474 | Ferrari Wavy Washer 10mm - 12601474 | $0.06 | Available, ships in 3-6 days |
| 11 | 10791021 | Ferrari Nut LHD - 10791021 | $1.25 | Available, ships in 3-6 days |
| 12 | 15811787 | Ferrari Protective Cap 17 x 10.5 - 15811787 | $1.53 | Available, ships in 3-6 days |
| 13 | 85450500 | Ferrari Windscreen Wiper Mounting Bracket Complete - 85450500 | $103.38 | Special order, ships in 7-14 days |
| 14 | 14305524 | Ferrari Allen Screw M6 x 30 - 14305524 | $0.27 | Available, ships in 3-6 days |
| 15 | 231618 | Ferrari Allen Head Screw M6x20 TCEI - 231618 | $0.57 | Available, ships in 3-6 days |
| 16 | 12644424 | Ferrari Washer 6.15-15 x 1 - 12644424 | $0.12 | Available, ships in 3-6 days |
| 17 | 826787 | Ferrari Compl. Windscreen Wiper Asse - 826787 | $51.67 | Special order, ships in 7-14 days |
| 18 | 194031 | Ferrari Flanged Nut M6 x 20 - 194031 | $1.21 | Available, ships in 3-6 days |
| 18 | 132877 | Ferrari Nut - 132877 | Superseded | Order 194031 instead |
| 19 | 206739 | Ferrari Tear Clip - 206739 | $16.37 | Available, ships in 3-6 days |
| 20 | 82198600 | Ferrari Filler Pipe Seal - 82198600 | $44.24 | Special order, ships in 7-14 days |
| 21 | 81633100 | Ferrari Fluid Level Sensor - 81633100 | $240.39 | Special order, ships in 7-14 days |
| 22 | 81633200 | Ferrari Gasket - 81633200 | $50.24 | Special order, ships in 7-14 days |
| 23 | 81632900 | Ferrari Windscreen Washer Pump - 81632900 | $172.84 | Available, ships in 3-6 days |
| 24 | 65511700 | Ferrari Seal For Washer Pump - 65511700 | $9.81 | Available, ships in 3-6 days |
