Ferrari Daytona SP3 — [VEHICLE TRIM] - E.56 - FUEL FILLER SEAT (diagram 0168)
Exploded view of the [vehicle trim] - e.56 - fuel filler seat on the Ferrari Daytona SP3, with 32 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.56 - FUEL FILLER SEAT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0168.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead | |
| 1 | 746770 | Ferrari Fuel Filler Flap - 746770 | $738.64 | Special order, ships in 7-14 days |
| 1 | 807578 | Ferrari FUEL FILLER FLAP - 807578 | $6,261.62 | Special order, ships in 7-14 days |
| 2 | 904763 | Ferrari Compl. Hinge - 904763 | $369.30 | Special order, ships in 7-14 days |
| 3 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 4 | 11566227 | Ferrari Screw 5x14 - 11566227 | $2.59 | Special order, ships in 7-14 days |
| 5 | 750733 | Ferrari Actuator Bracket - 750733 | $78.76 | Special order, ships in 7-14 days |
| 6 | 788574 | Ferrari Fuel Filler Flap Actuator - 788574 | $306.38 | Special order, ships in 7-14 days |
| 7 | 55020741 | Ferrari Bush - 55020741 | $86.15 | Special order, ships in 7-14 days |
| 7 | 67485800 | Ferrari Bush - 67485800 | $58.73 | Special order, ships in 7-14 days |
| 8 | 86730400 | Ferrari Rubber Pad - 86730400 | $2.68 | Special order, ships in 7-14 days |
| 8 | 87219800 | Ferrari Rubber Pad - 87219800 | $3.91 | Special order, ships in 7-14 days |
| 9 | 15538777 | Ferrari Screw 8x13 - 15538777 | $0.34 | Available, ships in 3-6 days |
| 10 | 749058 | Ferrari Actuator Cover - 749058 | $1,829.08 | Special order, ships in 7-14 days |
| 11 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
| 12 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 13 | 920172 | Ferrari Fuel Drain Pipe - 920172 | $17.46 | Special order, ships in 7-14 days |
| 14 | 13432270 | Ferrari Clip - 13432270 | $1.88 | Available, ships in 3-6 days |
| 15 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 16 | 10441590 | Ferrari P Clip Bracket With Sheath 16mm - 10441590 | $0.98 | Available, ships in 3-6 days |
| 17 | 87658800 | Ferrari Screw - 87658800 | Superseded | Order 14304187 instead |
| 17 | 14304187 | Ferrari Screw TCEI M5x12 - 14304187 | $0.46 | Available, ships in 3-6 days |
| 18 | 304634 | Ferrari Washer - 304634 | $1.46 | Special order, ships in 7-14 days |
| 19 | 86009300 | Ferrari Passacavo D.3.6-6Mm - 86009300 | $1.50 | Special order, ships in 7-14 days |
| 20 | 748672 | Ferrari Striker - 748672 | $20.66 | Special order, ships in 7-14 days |
| 21 | 748675 | Ferrari Shim Plate - 748675 | $10.83 | Special order, ships in 7-14 days |
| 22 | 85882600 | Ferrari Washer - 85882600 | $0.17 | Available, ships in 3-6 days |
| 22 | 12644478 | Ferrari Washer D. 6.45 - 15 x 1 - 12644478 | Superseded | Order 85882600 instead |
