Ferrari Daytona SP3 — [VEHICLE TRIM] - E.57.01 - AC SYSTEM - EVAPORATOR (diagram 0169)

Exploded view of the [vehicle trim] - e.57.01 - ac system - evaporator on the Ferrari Daytona SP3, with 51 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Daytona SP3 [VEHICLE TRIM] - E.57.01 - AC SYSTEM - EVAPORATOR exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
10442290Ferrari P Clip Bracket With Sheath - 10442290$1.42Special order, ships in 7-14 days
85801000Ferrari Underwindscreen Tray Inlet Seal - 85801000SupersededOrder 85800900 instead
12638108Ferrari Washer - 12638108SupersededOrder 12638178 instead
12638177Ferrari Washer - 12638177SupersededOrder 12638178 instead
61276300Ferrari Washer - 61276300SupersededOrder 12638178 instead
1912289Ferrari Hvac Unit - 912289$16,138.37Contact us to order
286057000Ferrari Firewall Flange Gasket - 86057000$124.74Special order, ships in 7-14 days
382046800Ferrari Front Sink - 82046800$344.21Special order, ships in 7-14 days
482046600Ferrari Sink For Defrost Ducting - 82046600$344.21Special order, ships in 7-14 days
583749200Ferrari Evaporator Sensor - 83749200$349.68Special order, ships in 7-14 days
6839975Ferrari Cable Harness - 839975$1,895.91Special order, ships in 7-14 days
7264880Ferrari Fan - 264880$1,304.98Special order, ships in 7-14 days
8264881Ferrari Speed Regulator - 264881$664.78Special order, ships in 7-14 days
987390400Ferrari TXV Service Kit - 87390400$860.56Special order, ships in 7-14 days
1068390100Ferrari Air Sensor - 68390100$21.60Available, ships in 3-6 days
1168391900Ferrari Screw - 68391900SupersededOrder 62771900 instead
1162771900Ferrari Screw D. 4.2 x 16 TBIC - 62771900$0.54Available, ships in 3-6 days
1268389800Ferrari Rubber Pad - 68389800$12.52Special order, ships in 7-14 days
13966106Ferrari Lin Bus Recirculation Actuat - 966106$91.90Special order, ships in 7-14 days
14966107Ferrari Actuator - 966107$91.77Special order, ships in 7-14 days
15966108Ferrari Actuator - 966108$91.77Special order, ships in 7-14 days
16966110Ferrari Actuator - 966110$91.77Special order, ships in 7-14 days
17966111Ferrari Actuator - 966111$91.77Special order, ships in 7-14 days
18966113Ferrari Actuator - 966113$91.77Special order, ships in 7-14 days
19966114Ferrari Actuator - 966114$91.77Special order, ships in 7-14 days
20966115Ferrari Actuator - 966115$91.77Special order, ships in 7-14 days
21966117Ferrari Actuator - 966117$91.77Special order, ships in 7-14 days
22840144Ferrari BRACKET - 840144Price on requestContact us for price and availability
2311223887Ferrari Clip - 11223887$1.02Special order, ships in 7-14 days
24293254Ferrari HVAC Condensation Drain Hose Connector - 293254$88.61Special order, ships in 7-14 days
25178052Ferrari Clip - 178052$3.26Available, ships in 3-6 days
25296778Ferrari Screw Collar 16- 27mm - 296778SupersededOrder 178052 instead
26904819Ferrari Air Intake Tray Assembly - 904819$5,423.98Special order, ships in 7-14 days
26904830Ferrari Air Intake Tray Assembly - 904830$5,377.09Special order, ships in 7-14 days
2782295100Ferrari 458/488/F8 Cabin Pollen Filter - 82295100$53.90In stock
28866851Ferrari Air Quality Sensor - 866851$161.94Special order, ships in 7-14 days
2986133600Ferrari Underwindscreen Tray Drain Tube - 86133600$295.43Special order, ships in 7-14 days
30206739Ferrari Tear Clip - 206739$16.37Available, ships in 3-6 days
3114304224Ferrari Screw M5 x 16 - 14304224$0.27Available, ships in 3-6 days
3212620374Ferrari Washer 5.30-12x0.8 - 12620374$0.12Available, ships in 3-6 days
3312638178Ferrari Washer 5.45-14x1 - 12638178$0.13Available, ships in 3-6 days
3485800900Ferrari Underwindscreen Tray Inlet Seal - 85800900$93.53Special order, ships in 7-14 days
35742109Ferrari Drain Pipe - 742109$320.06Special order, ships in 7-14 days
3610441990Ferrari P Clip Bracket With Sheath - 10441990$1.42Available, ships in 3-6 days
36291225Ferrari P clip Bracket With Sheath - 291225$7.86Special order, ships in 7-14 days
3713001690Ferrari Hose Clip 30-45mm - 13001690$2.61Available, ships in 3-6 days
3713001090Ferrari Hose Clip 70-90Mm - 13001090$2.82Available, ships in 3-6 days
3813046012Ferrari Nut - 13046012SupersededOrder 13046011 instead
39945965Ferrari Air Quality Sensor Fastener - 945965$64.00Special order, ships in 7-14 days
4015896410Ferrari NUT - 15896410Price on requestContact us for price and availability
