Ferrari Daytona SP3 — [VEHICLE TRIM] - E.58 - BADGES (diagram 0171)
Exploded view of the [vehicle trim] - e.58 - badges on the Ferrari Daytona SP3, with 24 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.58 - BADGES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0171.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12574115 | Ferrari Nut - 12574115 | Superseded | Order 169180 instead | |
| 12577811 | Ferrari Nut - 12577811 | Superseded | Order 169180 instead | |
| 12574111 | Ferrari Nyloc Nut - 12574111 | Superseded | Order 169180 instead | |
| 12574121 | Ferrari Nyloc Nut White - 12574121 | Superseded | Order 169180 instead | |
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead | |
| 1 | 973053 | Ferrari Front Emblem/Badge - 973053 | $368.80 | In stock |
| 1 | 65394800 | Ferrari Nose Emblem Badge - 65394800 | Superseded | Order 973053 instead |
| 2 | 169180 | Ferrari Nyloc Nut M5 x 6.3 - 169180 | $0.31 | Available, ships in 3-6 days |
| 3 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 4 | 833815 | Ferrari Squadra Corse Shield Badge - 833815 | $1,600.44 | Special order, ships in 7-14 days |
| 4 | 973296 | Ferrari Squadra Corse Shield Badge - 973296 | $1,822.04 | Special order, ships in 7-14 days |
| 5 | 775838 | Ferrari REAR BUMPER CAVALLINO RAMPANTE BADGE - 775838 | Price on request | Contact us for price and availability |
| 5 | 947766 | Ferrari REAR BUMPER CAVALLINO RAMPANTE BADGE - 947766 | Price on request | Contact us for price and availability |
| 6 | 808769 | Ferrari CAP NUT - 808769 | $7.59 | Special order, ships in 7-14 days |
| 6 | 16101777 | Ferrari Nut - 16101777 | $0.31 | Available, ships in 3-6 days |
| 7 | 775836 | Ferrari 2-Pin Ferrari Badge - 775836 | $108.31 | Special order, ships in 7-14 days |
| 7 | 896035 | Ferrari 2-Pin Ferrari Badge - 896035 | $192.03 | Special order, ships in 7-14 days |
| 8 | 84952000 | Ferrari Cosmetic Cap - 84952000 | $16.45 | Available, ships in 3-6 days |
| 9 | 950187 | Ferrari Badge Mounting - 950187 | $44.29 | Special order, ships in 7-14 days |
| 10 | 14440121 | Ferrari Screw 4X12 - 14440121 | $0.50 | Available, ships in 3-6 days |
| 11 | 84706300 | Ferrari Italian Flag Badge - 84706300 | Superseded | Order 988640 instead |
| 11 | 988640 | Ferrari Italian Flag Badge - 988640 | $835.97 | Available, ships in 3-6 days |
