Ferrari Daytona SP3 — [VEHICLE TRIM] - E.60 - FRONT SUBSTRUCTURE TRIM (diagram 0173)
Exploded view of the [vehicle trim] - e.60 - front substructure trim on the Ferrari Daytona SP3, with 26 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.60 - FRONT SUBSTRUCTURE TRIM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0173.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 80131500 | Ferrari Spray Nozzle - 80131500 | Superseded | Order 65191000 instead | |
| 11197779 | Ferrari Washer - 11197779 | Superseded | Order 11197774 instead | |
| 1 | 832428 | Ferrari COMPL. UNDERWINDSCREEN TRAY - 832428 | Price on request | Contact us for price and availability |
| 1 | 907905 | Ferrari Compl. Underwindscreen Tray - 907905 | $9,785.72 | Special order, ships in 7-14 days |
| 2 | 784079 | Ferrari RH Tray Lateral Extension - 784079 | $2,642.81 | Special order, ships in 7-14 days |
| 3 | 784077 | Ferrari LH Tray Lateral Extension - 784077 | $2,642.81 | Special order, ships in 7-14 days |
| 4 | 793793 | Ferrari Screw - 793793 | $15.28 | Special order, ships in 7-14 days |
| 4 | 86705000 | Ferrari Screw M5x10 TBFTX - 86705000 | $1.36 | Special order, ships in 7-14 days |
| 5 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
| 6 | 750159 | Ferrari Gasket - 750159 | $30.61 | Special order, ships in 7-14 days |
| 7 | 900194 | Ferrari Air Intake Tray Inlet Cover - 900194 | $1,829.08 | Special order, ships in 7-14 days |
| 8 | 84903900 | Ferrari Windscreen Wiper Spindle Seal - 84903900 | $71.38 | Special order, ships in 7-14 days |
| 9 | 13579101 | Ferrari Washer - 13579101 | $0.06 | Available, ships in 3-6 days |
| 9 | 86321000 | Ferrari Washer - 86321000 | $12.00 | Special order, ships in 7-14 days |
| 10 | 65191000 | Ferrari Spray Nozzle - 65191000 | $5.44 | Available, ships in 3-6 days |
| 11 | 799526 | Ferrari Threaded Insert - 799526 | $83.68 | Special order, ships in 7-14 days |
| 12 | 12638124 | Ferrari Washer - 12638124 | $0.08 | Available, ships in 3-6 days |
| 12 | 85882600 | Ferrari Washer - 85882600 | $0.17 | Available, ships in 3-6 days |
| 12 | 12644478 | Ferrari Washer D. 6.45 - 15 x 1 - 12644478 | Superseded | Order 85882600 instead |
| 13 | 936344 | Ferrari Vite Tbftx T25 M5X12 Nerinox - 936344 | $0.82 | Special order, ships in 7-14 days |
| 14 | 11197774 | Ferrari Conic Washer 6.4x12x1.2 - 11197774 | $0.12 | Available, ships in 3-6 days |
| 15 | 744096 | Ferrari Brake Fluid Reservoir Gasket - 744096 | $131.29 | Special order, ships in 7-14 days |
| 16 | 783111 | Ferrari Underwindscreen Tray Extensi - 783111 | $26.24 | Special order, ships in 7-14 days |
| 17 | 206739 | Ferrari Tear Clip - 206739 | $16.37 | Available, ships in 3-6 days |
| 19 | 166467 | Ferrari Wavy Washer D. 5 - 10 mm - 166467 | $1.80 | Available, ships in 3-6 days |
| 20 | 793794 | Ferrari Screw - 793794 | $14.84 | Special order, ships in 7-14 days |
