Ferrari Daytona SP3 — [VEHICLE TRIM] - E.61 - BATTERY INSTALLATION (diagram 0174)
Exploded view of the [vehicle trim] - e.61 - battery installation on the Ferrari Daytona SP3, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [VEHICLE TRIM] - E.61 - BATTERY INSTALLATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0174.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12643707 | Ferrari Washer - 12643707 | Superseded | Order 12643778 instead | |
| 12643777 | Ferrari Washer - 12643777 | Superseded | Order 12643778 instead | |
| 1 | 796740 | Ferrari Battery Carrier Tray - 796740 | $7,942.54 | Special order, ships in 7-14 days |
| 2 | 85629300 | Ferrari Screw M6 x 20 - 85629300 | $1.17 | Available, ships in 3-6 days |
| 3 | 13550224 | Ferrari Washer D 6.15-13x1 - 13550224 | $2.59 | Available, ships in 3-6 days |
| 4 | 948353 | Ferrari Compl. Strap Fastener Bracke - 948353 | $39.37 | Special order, ships in 7-14 days |
| 5 | 840591 | Ferrari Battery Absorber - 840591 | $130.47 | Special order, ships in 7-14 days |
| 6 | 86001300 | Ferrari Screw - 86001300 | $4.14 | Special order, ships in 7-14 days |
| 7 | 789292 | Ferrari Upper Battery Retainer Brack - 789292 | $78.76 | Special order, ships in 7-14 days |
| 8 | 796304 | Ferrari Rear Battery Fastener Tie-Ro - 796304 | $93.53 | Special order, ships in 7-14 days |
| 9 | 796294 | Ferrari Front Battery Fastener Tie-R - 796294 | $93.53 | Special order, ships in 7-14 days |
| 10 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 11 | 796202 | Ferrari Side Board - 796202 | $320.06 | Special order, ships in 7-14 days |
| 12 | 789294 | Ferrari Lower Battery Retainer Brack - 789294 | $1,181.86 | Special order, ships in 7-14 days |
| 13 | 89324200 | Ferrari WASHER - 89324200 | $1.36 | Special order, ships in 7-14 days |
| 14 | 12643778 | Ferrari Washer 6-18 x 1.5 - 12643778 | $0.54 | Available, ships in 3-6 days |
