Ferrari Daytona SP3 — [ELECTRICAL SYSTEM] - F.06 - ELECTRICAL SYSTEM CONTROL UNITS (diagram 0181)
Exploded view of the [electrical system] - f.06 - electrical system control units on the Ferrari Daytona SP3, with 32 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [ELECTRICAL SYSTEM] - F.06 - ELECTRICAL SYSTEM CONTROL UNITS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0181.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 908016 | Ferrari Headlamp Control Unit - 908016 | Superseded | Order 870717 instead | |
| 294559 | Ferrari PWM Command Signal For Fuel - 294559 | Superseded | Order 849386 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 863935 | Ferrari Body Computer - 863935 | $1,501.96 | Special order, ships in 7-14 days |
| 2 | 16285924 | Ferrari Screw - 16285924 | $0.40 | Available, ships in 3-6 days |
| 3 | 264097 | Ferrari Voltage Stabilizer - 264097 | $969.98 | In stock |
| 4 | 831850 | Ferrari Ncl A/C Black Box - 831850 | $1,598.19 | Special order, ships in 7-14 days |
| 5 | 885672 | Ferrari Bracket - 885672 | $135.39 | Special order, ships in 7-14 days |
| 6 | 337964 | Ferrari Power Window Lifter - 337964 | $14,836.88 | Contact us to order |
| 7 | 159147 | Ferrari Rubber Shim 100x50x4mm - 159147 | $1.67 | Available, ships in 3-6 days |
| 8 | 11223887 | Ferrari Clip - 11223887 | $1.02 | Special order, ships in 7-14 days |
| 9 | 293089 | Ferrari Power Steering Control Ecu - 293089 | $344.69 | Special order, ships in 7-14 days |
| 10 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 11 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 12 | 845377 | Ferrari Airbag ECU - 845377 | $984.88 | Special order, ships in 7-14 days |
| 13 | 742089 | Ferrari Airbag ECU Fastener Bracket - 742089 | $196.96 | Special order, ships in 7-14 days |
| 14 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 15 | 806960 | Ferrari Suspension Ecu - 806960 | $2,040.14 | Special order, ships in 7-14 days |
| 16 | 314815 | Ferrari Tpms ECU Antenna - 314815 | $983.50 | Special order, ships in 7-14 days |
| 16 | 314817 | Ferrari Tpms ECU Antenna - 314817 | $983.50 | Special order, ships in 7-14 days |
| 17 | 113647 | Ferrari Nyloc Nut - 113647 | $0.52 | Available, ships in 3-6 days |
| 18 | 849386 | Ferrari PWM Command Signal for Fuel Pumps - 849386 | $688.45 | Special order, ships in 7-14 days |
| 19 | 85692300 | Ferrari Screw M5 x 20 TBFTX - 85692300 | $0.65 | Available, ships in 3-6 days |
| 20 | 903095 | Ferrari Vehicle Lift Ecu - 903095 | $1,551.20 | Special order, ships in 7-14 days |
| 21 | 888552 | Ferrari Lifter ECU Bracket - 888552 | $369.30 | Special order, ships in 7-14 days |
| 22 | 870688 | Ferrari Brow Ecu - 870688 | $3,114.15 | Special order, ships in 7-14 days |
| 23 | 870717 | Ferrari Lights Control Ecu - 870717 | $467.15 | Special order, ships in 7-14 days |
| 24 | 805481 | Ferrari Parking Sensor Ecu - 805481 | $467.80 | Special order, ships in 7-14 days |
| 25 | 14059114 | Ferrari Nut M5 - 14059114 | $0.27 | Available, ships in 3-6 days |
| 26 | 86174900 | Ferrari Washer - 86174900 | $4.35 | Special order, ships in 7-14 days |
| 27 | 925745 | Ferrari Screw M5 x 35 TBFTX - 925745 | $3.03 | Special order, ships in 7-14 days |
| 28 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
