Ferrari Daytona SP3 — [ELECTRICAL SYSTEM] - F.10 - AUDIO UNIT (diagram 0185)
Exploded view of the [electrical system] - f.10 - audio unit on the Ferrari Daytona SP3, with 43 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [ELECTRICAL SYSTEM] - F.10 - AUDIO UNIT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0185.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 242694 | Ferrari GPS Antenna - 242694 | Price on request | Contact us for price and availability | |
| 331961 | Ferrari GPS Antenna - 331961 | $154.46 | Special order, ships in 7-14 days | |
| 931307432 | Ferrari Navigation System Gps Antenna - 931307432 | Superseded | Order 789209 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 288974 | Ferrari USB Socket - 288974 | Superseded | Order 303226 instead | |
| 1 | 869913 | Ferrari Nit - 869913 | $15,765.50 | Contact us to order |
| 1 | 869992 | Ferrari Nit - 869992 | $17,812.70 | Contact us to order |
| 1 | 869997 | Ferrari Nit - 869997 | $15,624.81 | Contact us to order |
| 1 | 870013 | Ferrari Nit - 870013 | $14,574.24 | Contact us to order |
| 2 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 2 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 3 | 918149 | Ferrari Am/Fm ? Fm2/Dab Antenna Cabl - 918149 | $418.56 | Special order, ships in 7-14 days |
| 3 | 839818 | Ferrari Am/Fm/Fm2 Antenna Cable - 839818 | $344.69 | Special order, ships in 7-14 days |
| 3 | 839846 | Ferrari Am/Fm/Fm2 Antenna Cable - 839846 | $344.69 | Special order, ships in 7-14 days |
| 4 | 771350 | Ferrari Fm2/Dab Amplifier - 771350 | $344.21 | Special order, ships in 7-14 days |
| 4 | 771351 | Ferrari FM2/DAB Amplifier - 771351 | $226.19 | Special order, ships in 7-14 days |
| 4 | 771352 | Ferrari Fm2/Dab Amplifier - 771352 | $270.44 | Special order, ships in 7-14 days |
| 5 | 331962 | Ferrari Am/Fm Amplifier - 331962 | $189.31 | Special order, ships in 7-14 days |
| 5 | 771349 | Ferrari Am/Fm Amplifier - 771349 | $240.94 | Special order, ships in 7-14 days |
| 6 | 848237 | Ferrari RH Amplifier Bracket - 848237 | $56.60 | Special order, ships in 7-14 days |
| 7 | 848240 | Ferrari LH Amplifier Bracket - 848240 | $56.60 | Special order, ships in 7-14 days |
| 8 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
| 9 | 969204 | Ferrari Antenna Bt-Wifi Dual Band - 969204 | $96.14 | Special order, ships in 7-14 days |
| 10 | 251541 | Ferrari Tweeter - 251541 | $56.79 | Special order, ships in 7-14 days |
| 11 | 334279 | Ferrari Woofer - 334279 | $183.56 | Special order, ships in 7-14 days |
| 12 | 85834000 | Ferrari Screw M5 x 25 - 85834000 | $0.71 | Special order, ships in 7-14 days |
| 13 | 789209 | Ferrari GPS Antenna - 789209 | $155.15 | Special order, ships in 7-14 days |
| 14 | 269772 | Ferrari Twiddler - 269772 | $109.25 | Special order, ships in 7-14 days |
| 15 | 85691900 | Ferrari Screw M5 x 8 TBFTX - 85691900 | $0.65 | Available, ships in 3-6 days |
| 16 | 875005 | Ferrari USB Splitter - Apple Car Play Version - 875005 | $1,598.19 | Contact us to order |
| 17 | 918102 | Ferrari Usb Splitter-Smrt Port Cable - 918102 | $393.93 | Special order, ships in 7-14 days |
| 18 | 303226 | Ferrari USB Socket - 303226 | $100.78 | Special order, ships in 7-14 days |
| 19 | 918111 | Ferrari Usb Splitter-Base Socket Cab - 918111 | $393.93 | Special order, ships in 7-14 days |
| 20 | 848476 | Ferrari Presa Usb Smartphone Project - 848476 | $211.43 | Special order, ships in 7-14 days |
| 21 | 85630200 | Ferrari Screw - 85630200 | Superseded | Order 65752800 instead |
| 21 | 65752800 | Ferrari Screw M4 x 10 TBEI - 65752800 | $4.12 | Available, ships in 3-6 days |
| 22 | 867192 | Ferrari Sdars Antenna - 867192 | $328.27 | Special order, ships in 7-14 days |
| 23 | 951766 | Ferrari 4-Way Usb Hub For Dsrc Jrc - 951766 | $1,598.19 | Special order, ships in 7-14 days |
| 24 | 928349 | Ferrari Compl. Drsc-Vics Kit - 928349 | $14,542.12 | Special order, ships in 7-14 days |
| 25 | 928354 | Ferrari Dsrc/Hub Cable - 928354 | $130.29 | Special order, ships in 7-14 days |
| 26 | 958192 | Ferrari Dsrc Beacon Antenna Cable - 958192 | $66.35 | Special order, ships in 7-14 days |
| 27 | 958191 | Ferrari Dsrc 5.8Ghz Advance Antenna - 958191 | $181.93 | Special order, ships in 7-14 days |
| 28 | 70006011 | Ferrari Sd Card Navigation Maps - 70006011 | $1,256.70 | Special order, ships in 7-14 days |
