Ferrari Daytona SP3 — [ELECTRICAL SYSTEM] - F.13 - DATA LOGGER SYSTEM (diagram 0188)
Exploded view of the [electrical system] - f.13 - data logger system on the Ferrari Daytona SP3, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Daytona SP3 [ELECTRICAL SYSTEM] - F.13 - DATA LOGGER SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/daytona-sp3/0188.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 918042 | Ferrari Front Bumper Camera Cable - 918042 | $226.49 | Special order, ships in 7-14 days |
| 2 | 852295 | Ferrari Rear Camera - 852295 | $2,248.03 | Special order, ships in 7-14 days |
| 2 | 818615 | Ferrari Surround Camera - 818615 | $1,967.03 | Special order, ships in 7-14 days |
| 4 | 813444 | Ferrari Ndc Ecu - 813444 | $7,576.71 | Special order, ships in 7-14 days |
| 5 | 160472 | Ferrari Nut - 160472 | $4.35 | Special order, ships in 7-14 days |
| 6 | 815940 | Ferrari Mirror Camera - 815940 | $1,083.38 | Special order, ships in 7-14 days |
| 7 | 812891 | Ferrari Screw - 812891 | $0.73 | Special order, ships in 7-14 days |
