Ferrari Enzo — Doors - Power Window (diagram 112)

Exploded view of the doors - power window on the Ferrari Enzo, with 39 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Enzo Doors - Power Window exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
166539100Ferrari RH Inner Door Frame - 66539100$3,234.66Special order, ships in 7-14 days
166536300Ferrari LH Inner Door Frame - 66536300$3,234.66Special order, ships in 7-14 days
266567400Ferrari RH Door Glass Lifter - 66567400$565.68Special order, ships in 7-14 days
266561500Ferrari LH Door Glass Lifter - 66561500$565.68Special order, ships in 7-14 days
366561400Ferrari RH Rear Guide - 66561400$1,028.04Special order, ships in 7-14 days
366560500Ferrari LH Rear Guide - 66560500$1,028.04Special order, ships in 7-14 days
410902224Ferrari Screw M6 x 16 - 10902224$0.12Available, ships in 3-6 days
512644424Ferrari Washer 6.15-15 x 1 - 12644424$0.12Available, ships in 3-6 days
612601274Ferrari Wavy Washer 6mm - 12601274$1.04Available, ships in 3-6 days
714305220Ferrari Screw - 14305220$0.31Available, ships in 3-6 days
814498824Ferrari Washer D. 6.4 - 16.3 - 14498824$0.27Available, ships in 3-6 days
814498804Ferrari Washer - 14498804SupersededOrder 14498824 instead
912620474Ferrari Wavy Washer - 12620474$0.12Available, ships in 3-6 days
1012578211Ferrari Flanged Nyloc Nut - 12578211$0.57Special order, ships in 7-14 days
1166805600Ferrari RH Rear Bracket - 66805600$97.88Special order, ships in 7-14 days
1166571800Ferrari LH Rear Bracket - 66571800$117.47Special order, ships in 7-14 days
1267503500Ferrari Rivet - 67503500Price on requestContact us for price and availability
1366805700Ferrari Front Bracket - 66805700$117.47Special order, ships in 7-14 days
1467384600Ferrari Window Winder Handle - 67384600Price on requestContact us for price and availability
1467384900Ferrari Lining - 67384900Price on requestContact us for price and availability
1567057000Ferrari Trim Cap - 67057000Price on requestContact us for price and availability
1667552200Ferrari Winder Knob - 67552200Price on requestContact us for price and availability
1710725914Ferrari Nut M6 x 4 - 10725914$0.19Available, ships in 3-6 days
1814304324Ferrari Allen Screw - 14304324$2.09Available, ships in 3-6 days
1912620374Ferrari Washer 5.30-12x0.8 - 12620374$0.12Available, ships in 3-6 days
2066563100Ferrari RH Door Glass - 66563100$1,087.88Contact us to order
2066563000Ferrari LH Door Glass - 66563000$1,087.88Contact us to order
2166538900Ferrari RH Door Glass Rubber - 66538900$1,805.88Special order, ships in 7-14 days
2166561300Ferrari LH Door Glass Rubber - 66561300Price on requestContact us for price and availability
2212643724Ferrari/Maserati Washer - 12643724$0.20In stock
2214499324Ferrari Washer - 14499324SupersededOrder 12643724 instead
2364854600Ferrari Adjustment Pin - 64854600$29.34Special order, ships in 7-14 days
12640624Ferrari Plain Washer 6mm - 12640624$0.31Available, ships in 3-6 days
12601224Ferrari Washer - 12601224SupersededOrder 12601274 instead
12605370Ferrari Washer - 12605370SupersededOrder 12601274 instead
12605371Ferrari Washer - 12605371SupersededOrder 12601274 instead
14499301Ferrari Washer - 14499301SupersededOrder 12643724 instead
680232Ferrari Washer - 680232SupersededOrder 12601274 instead
12605374Ferrari Wavy Washer - 12605374SupersededOrder 12601274 instead
