Ferrari F12 Berlinetta — Power Steering System (diagram 027)
Exploded view of the power steering system on the Ferrari F12 Berlinetta, with 30 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 261826 | Ferrari Brake Servo - 261826 | $896.08 | Available, ships in 3-6 days |
| 2 | 259047 | Ferrari 458/488/812/F12 Brake Fluid Reservoir - 259047 | $67.78 | In stock |
| 3 | 283752 | Ferrari Kaiser Pipe Complete With Valves LHD - 283752 | Superseded | Order 293078 instead |
| 3 | 293078 | Ferrari Kaiser Pipe Complete With Valves LHD - 293078 | $807.74 | Special order, ships in 7-14 days |
| 3 | 293079 | Ferrari Kaiser Pipe Complete With Valves RHD - 293079 | $783.26 | Special order, ships in 7-14 days |
| 4 | 284403 | Ferrari F12 Berlinetta Brake Booster Pipe - 284403 | $142.91 | In stock |
| 4 | 290226 | Ferrari Pipe From Kayser Valve To Brake Servo RHD - 290226 | $129.70 | Special order, ships in 7-14 days |
| 4 | 282716 | Ferrari Pipe From Kayser Valve To Brake Servo LHD - 282716 | $269.23 | Special order, ships in 7-14 days |
| 4 | 290224 | Ferrari Pipe From Kayser Valve To Brake Servo RHD - 290224 | $293.71 | Special order, ships in 7-14 days |
| 5 | 248081 | Ferrari Elbow Union Retainer Plate - 248081 | $66.35 | Special order, ships in 7-14 days |
| 6 | 237586 | Ferrari Elbow Union For Brake Master Cylinder - 237586 | $13.74 | Special order, ships in 7-14 days |
| 7 | 287873 | Ferrari Rubber Pipe From Tank RHD - 287873 | $127.82 | Special order, ships in 7-14 days |
| 7 | 276960 | Ferrari Rubber Pipe From Tank LHD - 276960 | $83.20 | Special order, ships in 7-14 days |
| 8 | 287874 | Ferrari Rubber Pipe From Tank RHD - 287874 | $120.46 | Special order, ships in 7-14 days |
| 8 | 276961 | Ferrari Rubber Pipe From Tank LHD - 276961 | $80.75 | Special order, ships in 7-14 days |
| 9 | 13432070 | Ferrari/Maserati Screw Collar / Hose Clamp - 13432070 | $0.95 | In stock |
| 10 | 289128 | Ferrari Brake Fluid Reservoir Bracket RHD - 289128 | $88.49 | Special order, ships in 7-14 days |
| 10 | 275638 | Ferrari Brake Fluid Reservoir Bracket LHD - 275638 | $58.73 | Special order, ships in 7-14 days |
| 11 | 11625824 | Ferrari Screw 6x18 - 11625824 | $0.71 | Available, ships in 3-6 days |
| 12 | 13434670 | Ferrari Screw Collar D16.2mm - 13434670 | $1.44 | Available, ships in 3-6 days |
| 13 | 291401 | Ferrari Vacuum Pipe Mounting Bracket - 291401 | $15.39 | Special order, ships in 7-14 days |
| 14 | 267177 | Ferrari Clip D.20-21.5 - 267177 | $2.01 | Special order, ships in 7-14 days |
| 15 | 267030 | Ferrari Heat Shield LHD - 267030 | $36.69 | Special order, ships in 7-14 days |
| 15 | 297984 | Ferrari Heat Shield RHD - 297984 | $210.49 | Special order, ships in 7-14 days |
| 16 | 14040611 | Ferrari Nut M6 - 14040611 | $0.57 | Available, ships in 3-6 days |
| 17 | 289129 | Ferrari Brake Fluid Reservoir Internal Bracket - 289129 | $78.66 | Special order, ships in 7-14 days |
| 19 | 272185 | Ferrari Clip - 272185 | $3.26 | Special order, ships in 7-14 days |
| 20 | 297474 | Ferrari Bracket - 297474 | $31.93 | Special order, ships in 7-14 days |
| 21 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead |
