Ferrari F8 Spider — [GENERAL] - A.1 - SPARE ASSEMBLY UNITS (diagram 0001)
Exploded view of the [general] - a.1 - spare assembly units on the Ferrari F8 Spider, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [GENERAL] - A.1 - SPARE ASSEMBLY UNITS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0001.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 322647 | Ferrari Dual Clutch Gearbox Complete - 322647 | Superseded | Order 807337 instead | |
| 324234 | Ferrari Dual Clutch Gearbox Complete - 324234 | Superseded | Order 807337 instead | |
| 1 | 325923 | Ferrari Engine Gasket Set - 325923 | $2,040.14 | Special order, ships in 7-14 days |
| 2 | 985000334 | Ferrari Short Block F8 - 985000334 | $67,853.72 | Contact us to order |
| 3 | 807337 | Ferrari Dual Clutch Gearbox Complete - 807337 | $48,415.83 | Contact us to order |
| 4 | 873159 | Ferrari Short Block Gasket Kit - 873159 | $344.69 | Special order, ships in 7-14 days |
