Ferrari F8 Spider — [ENGINE] - B.19 - VACUUM PUMP (diagram 0024)
Exploded view of the [engine] - b.19 - vacuum pump on the Ferrari F8 Spider, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [ENGINE] - B.19 - VACUUM PUMP exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0024.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 834367 | Ferrari Screw 8x25 - 834367 | Superseded | Order 231628 instead | |
| 1 | 341928 | Ferrari Depressore Bosch - 341928 | $1,181.86 | Special order, ships in 7-14 days |
| 2 | 338653 | Ferrari Bracket - 338653 | $27.06 | Special order, ships in 7-14 days |
| 3 | 231628 | Ferrari Screw 8x25 - 231628 | $1.15 | Special order, ships in 7-14 days |
| 4 | 333545 | Ferrari Coperchio Per Sede Depresso - 333545 | $150.17 | Special order, ships in 7-14 days |
| 5 | 335257 | Ferrari Gasket - 335257 | $29.52 | Special order, ships in 7-14 days |
| 6 | 338896 | Ferrari Bracket - 338896 | $23.86 | Special order, ships in 7-14 days |
| 7 | 839366 | Ferrari Bumper - 839366 | $15.29 | Special order, ships in 7-14 days |
| 7 | 951041 | Ferrari Bumper - 951041 | $15.95 | Special order, ships in 7-14 days |
