Ferrari F8 Spider — [MECHANICAL SYSTEM] - D.33 - PARKING BRAKE CONTROL (diagram 0088)
Exploded view of the [mechanical system] - d.33 - parking brake control on the Ferrari F8 Spider, with 4 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [MECHANICAL SYSTEM] - D.33 - PARKING BRAKE CONTROL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0088.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 340412 | Ferrari Ecm Rear Calliper Control Un - 340412 | Superseded | Order 933950 instead | |
| 1 | 933950 | Ferrari ECM Rear Calliper Control Unit - 933950 | $1,625.07 | Available, ships in 3-6 days |
| 2 | 11612726 | Ferrari Screw - 11612726 | $1.42 | Special order, ships in 7-14 days |
| 3 | 935261 | Ferrari Epb ECU Film - 935261 | $29.52 | Special order, ships in 7-14 days |
