Ferrari F8 Spider — [VEHICLE TRIM] - E.6 - LATERAL SUBSTRUCTURE (diagram 0102)
Exploded view of the [vehicle trim] - e.6 - lateral substructure on the Ferrari F8 Spider, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [VEHICLE TRIM] - E.6 - LATERAL SUBSTRUCTURE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0102.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 82992200 | Ferrari LH Front Endpiece - 82992200 | $146.84 | Special order, ships in 7-14 days | |
| 86675800 | Ferrari LH Front Section Pillar Flange - 86675800 | $183.56 | Special order, ships in 7-14 days | |
| 86744200 | Ferrari LH Lock Striker Reinforcemen - 86744200 | Superseded | Order 86744211 instead | |
| 82820400 | Ferrari LH Rear Endpiece - 82820400 | $212.92 | Special order, ships in 7-14 days | |
| 83814700 | Ferrari LH Rear Endpiece - 83814700 | $178.65 | Special order, ships in 7-14 days | |
| 86675900 | Ferrari RH Front Element Pillar Flange - 86675900 | Superseded | Order 86675911 instead | |
| 82992100 | Ferrari RH Front Endpiece - 82992100 | $146.84 | Special order, ships in 7-14 days | |
| 86744400 | Ferrari RH Lock Striker Reinforcemen - 86744400 | Superseded | Order 86744411 instead | |
| 83371800 | Ferrari RH Rear Endpiece - 83371800 | $212.92 | Special order, ships in 7-14 days | |
| 83815000 | Ferrari RH Rear Endpiece - 83815000 | $178.65 | Special order, ships in 7-14 days | |
| 1 | 86675911 | Ferrari A Pillar Flange. Front RH El - 86675911 | $443.17 | Special order, ships in 7-14 days |
| 2 | 82992111 | Ferrari RH Front Endpiece - 82992111 | $640.17 | Special order, ships in 7-14 days |
| 3 | 83815011 | Ferrari RH Rear Endpiece - 83815011 | $517.04 | Special order, ships in 7-14 days |
| 4 | 83814711 | Ferrari LH Rear Endpiece - 83814711 | $517.04 | Special order, ships in 7-14 days |
| 5 | 86675811 | Ferrari A Pillar Flange. Front LH Se - 86675811 | $443.17 | Special order, ships in 7-14 days |
| 6 | 82992211 | Ferrari LH Front Endpiece - 82992211 | $640.17 | Special order, ships in 7-14 days |
| 7 | 86744411 | Ferrari RH Lock Striker Reinforcemen - 86744411 | $664.78 | Special order, ships in 7-14 days |
| 8 | 86744211 | Ferrari LH Lock Striker Reinforcemen - 86744211 | $664.78 | Special order, ships in 7-14 days |
| 9 | 12626021 | Ferrari Washer - 12626021 | $0.82 | Special order, ships in 7-14 days |
| 10 | 16287234 | Ferrari SCREW - 16287234 | $1.05 | Available, ships in 3-6 days |
