Ferrari F8 Spider — [VEHICLE TRIM] - E.13.02 - ROOF - KINEMATICS (diagram 0110)

Exploded view of the [vehicle trim] - e.13.02 - roof - kinematics on the Ferrari F8 Spider, with 54 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari F8 Spider [VEHICLE TRIM] - E.13.02 - ROOF - KINEMATICS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14054042Ferrari Nut - 14054042SupersededOrder 168698 instead
14054048Ferrari Nut - 14054048SupersededOrder 168698 instead
80415900Ferrari Screw - 80415900$32.60Available, ships in 3-6 days
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
12640606Ferrari Washer - 12640606SupersededOrder 12640678 instead
12640608Ferrari Washer - 12640608SupersededOrder 12640678 instead
12640677Ferrari Washer - 12640677SupersededOrder 12640678 instead
124338Ferrari Washer D. 8 - 25 x 3 - 124338$14.55Available, ships in 3-6 days
1850047Ferrari Compl. RH Cover Lifter Mecha - 850047$2,345.00Special order, ships in 7-14 days
183977700Ferrari RH Cover Lifter Mechanism Complete - 83977700$1,600.44Special order, ships in 7-14 days
2850059Ferrari Compl. LH Cover Lifter Mecha - 850059$2,274.65Special order, ships in 7-14 days
283977600Ferrari LH Cover Lifter Mechanism Complete - 83977600$1,600.44Special order, ships in 7-14 days
388036000Ferrari Cable Harness With RH Cover Lift Sensor Complete - 88036000$664.78Special order, ships in 7-14 days
488035900Ferrari Cable Harness With LH Cover Lift Sensor Complete - 88035900$566.30Special order, ships in 7-14 days
582271400Ferrari Screw with Washer M8 x 25 TE - 82271400$2.59Available, ships in 3-6 days
6219344Ferrari Washer D8.5x24x - 219344SupersededOrder 124338 instead
784807000Ferrari Spacer 0.5mm - 84807000$8.82Available, ships in 3-6 days
784807100Ferrari Spacer 1.0mm - 84807100$8.82Available, ships in 3-6 days
784842000Ferrari Spacer 3.0mm - 84842000$10.81Available, ships in 3-6 days
883978400Ferrari RH Flap Inner Shell - 83978400$1,231.11Special order, ships in 7-14 days
887646500Ferrari RH Flap Mechanism - 87646500SupersededOrder 83978400 instead
983978300Ferrari LH Flap Inner Shell - 83978300$1,231.11Special order, ships in 7-14 days
987551100Ferrari LH Flap Mechanism - 87551100SupersededOrder 83978300 instead
1083978100Ferrari LH Bumper Complete - 83978100$13.49Special order, ships in 7-14 days
1113046112Ferrari Nut - 13046112$0.46Available, ships in 3-6 days
1284256000Ferrari RH Rear Centring Plate - 84256000$86.15Special order, ships in 7-14 days
1384256100Ferrari LH Rear Centring Plate - 84256100Price on requestContact us for price and availability
1416286127Ferrari Screw 6x20 - 16286127$0.82Available, ships in 3-6 days
1512640678Ferrari Washer 6.15x25x2 - 12640678$3.47Available, ships in 3-6 days
1683977800Ferrari Latch System Complete - 83977800$3,788.88Special order, ships in 7-14 days
17749652Ferrari RH Striker - 749652$958.91Special order, ships in 7-14 days
1783978000Ferrari RH Striker Complete - 83978000$663.86Special order, ships in 7-14 days
1883977900Ferrari LH Striker Complete - 83977900$549.71Available, ships in 3-6 days
1984643500Ferrari RH Bracket - 84643500$21.14Special order, ships in 7-14 days
2084643400Ferrari LH Bracket - 84643400$21.14Special order, ships in 7-14 days
2186496000Ferrari RH Windscreen Striker Plate - 86496000$100.93Special order, ships in 7-14 days
2286495900Ferrari LH Windscreen Striker Plate - 86495900$100.93Special order, ships in 7-14 days
2384503800Ferrari Shim Kit For Adjusting Roof Relative To Windscreen - 84503800$78.66Special order, ships in 7-14 days
2485692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
2512637878Ferrari Washer - 12637878$0.19Available, ships in 3-6 days
26168698Ferrari Nut M5 x 11 - 168698$3.68Available, ships in 3-6 days
2711617624Ferrari Screw - 11617624SupersededOrder 16287224 instead
2716287224Ferrari Screw M8x25 - 16287224$0.82Available, ships in 3-6 days
2812647024Ferrari Washer - 12647024$1.02Available, ships in 3-6 days
2914305334Ferrari Screw M6 x 20 - 14305334$0.38Available, ships in 3-6 days
3012646624Ferrari Washer 6.15-15x1.5 - 12646624$0.40Available, ships in 3-6 days
3111087776Ferrari Circlip - 11087776$0.13Available, ships in 3-6 days
3285529200Ferrari Roof/hood Pulley Kit - 85529200$590.91Special order, ships in 7-14 days
3383979200Ferrari RH Hinge Complete - 83979200$418.56Special order, ships in 7-14 days
3483979300Ferrari LH Hinge Complete - 83979300$418.56Special order, ships in 7-14 days
35242384Ferrari Clip - 242384$0.59Available, ships in 3-6 days
36919383Ferrari Clip Omega - 919383$1.55Special order, ships in 7-14 days
37817129Ferrari Clip - 817129$1.36Special order, ships in 7-14 days
