Ferrari F8 Spider — [VEHICLE TRIM] - E.22 - FRONT AIR INTAKES (diagram 0121)
Exploded view of the [vehicle trim] - e.22 - front air intakes on the Ferrari F8 Spider, with 24 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [VEHICLE TRIM] - E.22 - FRONT AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0121.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 862145 | Ferrari Compl. Upper Part of RH Front Semi-Duct - 862145 | $590.91 | Special order, ships in 7-14 days |
| 2 | 862162 | Ferrari Semiconvogl. Ant. Sx Parte S - 862162 | $590.91 | Special order, ships in 7-14 days |
| 3 | 896082 | Ferrari Front Duct for RH Lower Lateral Air Vent - 896082 | $27.06 | Special order, ships in 7-14 days |
| 4 | 896118 | Ferrari Conv.Ant.Usc. Aria Lat.Sx Cp - 896118 | $64.00 | Special order, ships in 7-14 days |
| 5 | 80874100 | Ferrari Screw Torx - 80874100 | $1.97 | Available, ships in 3-6 days |
| 6 | 85629300 | Ferrari Screw M6 x 20 - 85629300 | $1.17 | Available, ships in 3-6 days |
| 7 | 879943 | Ferrari RH Upper Brake Cooling Duct - 879943 | $91.08 | Special order, ships in 7-14 days |
| 8 | 879944 | Ferrari LH Upper Brake Cooling Duct - 879944 | $91.08 | Special order, ships in 7-14 days |
| 9 | 70006729 | Ferrari COMPL. RH BRAKE AIR INTAKE - 70006729 | Price on request | Contact us for price and availability |
| 9 | 874574 | Ferrari Compl. RH Brake Air Intake - 874574 | $709.82 | Special order, ships in 7-14 days |
| 9 | 881792 | Ferrari Compl. RH Brake Air Intake - 881792 | $5,956.31 | Special order, ships in 7-14 days |
| 10 | 70006730 | Ferrari COMPL. LH BRAKE AIR INTAKE - 70006730 | Price on request | Special order, ships in 7-14 days |
| 10 | 881787 | Ferrari Compl. LH Brake Air Intake - 881787 | $5,956.31 | Special order, ships in 7-14 days |
| 10 | 874576 | Ferrari Complete LH Brake Air Intake - 874576 | $714.03 | Special order, ships in 7-14 days |
| 11 | 11620724 | Ferrari Screw - 11620724 | $1.69 | Available, ships in 3-6 days |
| 12 | 80874300 | Ferrari Clip - 80874300 | $1.97 | Available, ships in 3-6 days |
| 13 | 859732 | Ferrari RH Headlight Fastener Bracket - 859732 | $59.07 | Special order, ships in 7-14 days |
| 14 | 859733 | Ferrari LH Headlight Fastener Bracket - 859733 | $59.07 | Special order, ships in 7-14 days |
| 15 | 66927700 | Ferrari Bracket with Collar - 66927700 | $1.99 | Available, ships in 3-6 days |
| 16 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 16 | 233600 | Ferrari/Maserati Screw - 233600 | $1.98 | In stock |
| 17 | 949118 | Ferrari Compl. LH Headlamp Guide - 949118 | $23.86 | Special order, ships in 7-14 days |
| 17 | 949149 | Ferrari Compl. RH Headlamp Guide - 949149 | $23.86 | Special order, ships in 7-14 days |
| 18 | 15689809 | Ferrari Screw D. 4.2 x 19 TBFIC - 15689809 | $0.27 | Available, ships in 3-6 days |
