Ferrari F8 Spider — [VEHICLE TRIM] - E.26 - REAR SCREEN (diagram 0125)
Exploded view of the [vehicle trim] - e.26 - rear screen on the Ferrari F8 Spider, with 18 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [VEHICLE TRIM] - E.26 - REAR SCREEN exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0125.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 84766100 | Ferrari Cap - 84766100 | Superseded | Order 85148300 instead | |
| 82201200 | Ferrari External Rear Screen Seal - 82201200 | Superseded | Order 891744 instead | |
| 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead | |
| 13046012 | Ferrari Nut - 13046012 | Superseded | Order 13046011 instead | |
| 1 | 82202400 | Ferrari Rear Screen - 82202400 | $1,159.97 | Contact us to order |
| 2 | 83072100 | Ferrari Rear Screen Lifter - 83072100 | $1,466.38 | Special order, ships in 7-14 days |
| 3 | 82201100 | Ferrari Internal Rear Screen Seal - 82201100 | $911.01 | Special order, ships in 7-14 days |
| 4 | 891744 | Ferrari External Rear Screen Seal - 891744 | $875.44 | Special order, ships in 7-14 days |
| 5 | 85148300 | Ferrari Cap - 85148300 | $5.04 | Special order, ships in 7-14 days |
| 6 | 84413900 | Ferrari Shim - 84413900 | $5.44 | Special order, ships in 7-14 days |
| 6 | 85422500 | Ferrari Shim - 85422500 | $8.93 | Special order, ships in 7-14 days |
| 7 | 84413000 | Ferrari Plate - 84413000 | $24.02 | Special order, ships in 7-14 days |
| 8 | 155751 | Ferrari Clip - 155751 | $8.49 | Available, ships in 3-6 days |
| 8 | 156198 | Ferrari Clip - 156198 | Superseded | Order 155751 instead |
| 9 | 13832101 | Ferrari Flanged Nut M6 - 13832101 | $0.27 | Available, ships in 3-6 days |
| 10 | 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days |
| 11 | 85691900 | Ferrari Screw M5 x 8 TBFTX - 85691900 | $0.65 | Available, ships in 3-6 days |
| 12 | 84801200 | Ferrari Adhesive Strip - 84801200 | $13.99 | Special order, ships in 7-14 days |
