Ferrari F8 Spider — [VEHICLE TRIM] - E.29.02 - DOORS - OPENING MECHANISMS AND HINGES (diagram 0129)

Exploded view of the [vehicle trim] - e.29.02 - doors - opening mechanisms and hinges on the Ferrari F8 Spider, with 46 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari F8 Spider [VEHICLE TRIM] - E.29.02 - DOORS - OPENING MECHANISMS AND HINGES exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
82629100Ferrari Cable Grommet - 82629100SupersededOrder 898656 instead
14569480Ferrari Clip 10x3.8 Black - 14569480$0.54Available, ships in 3-6 days
83982900Ferrari Hexagonal Pillar - 83982900SupersededOrder 87940300 instead
85730900Ferrari LH Door Lock LHD - 85730900SupersededOrder 785970 instead
85731000Ferrari LH Door Lock RHD - 85731000$318.19Special order, ships in 7-14 days
85730800Ferrari RH Door Lock LHD - 85730800SupersededOrder 785971 instead
85731100Ferrari RH Door Lock RHD - 85731100SupersededOrder 785975 instead
187217610Ferrari LH Outer Door Handle - 87217610$517.04Special order, ships in 7-14 days
187217710Ferrari RH Outer Door Handle - 87217710$517.04Special order, ships in 7-14 days
280365900Ferrari Screw M4 x 12 TSEI - 80365900$0.31Available, ships in 3-6 days
387217400Ferrari LH Door Handle Seal - 87217400$37.18Special order, ships in 7-14 days
387217500Ferrari RH Door Handle Seal - 87217500$37.18Available, ships in 3-6 days
487290600Ferrari LH Outer Door Handle Module - 87290600$369.30Special order, ships in 7-14 days
487290700Ferrari RH Outer Door Handle Module - 87290700$369.30Special order, ships in 7-14 days
580821900Ferrari Door Handle Spacer - 80821900$12.21Special order, ships in 7-14 days
688007300Ferrari Door Handle Spacer LHD - 88007300$6.54Special order, ships in 7-14 days
762239900Ferrari Pin - 62239900$9.56Available, ships in 3-6 days
887940300Ferrari Hexagonal Pillar - 87940300$34.40Special order, ships in 7-14 days
914059121Ferrari Nut M5 - 14059121$0.31Available, ships in 3-6 days
10785970Ferrari LH Door Lock LHD - 785970$243.40Special order, ships in 7-14 days
10785974Ferrari LH Door Lock RHD - 785974$243.40Special order, ships in 7-14 days
10785971Ferrari RH Door Lock LHD - 785971$243.40Special order, ships in 7-14 days
10785975Ferrari RH Door Lock RHD - 785975$243.40Special order, ships in 7-14 days
1185478900Ferrari SCREW - 85478900$2.13Available, ships in 3-6 days
1214506587Ferrari Rubber Grommet - 14506587$0.38Available, ships in 3-6 days
1386622600Ferrari Inner Door Handle Bowden Cable - 86622600$115.54Special order, ships in 7-14 days
13895642Ferrari Inner Door Handle Bowden Cable - 895642$132.75Special order, ships in 7-14 days
1482936500Ferrari Protective Sheath For Internal Handle Bowden Cable - 82936500$4.39Special order, ships in 7-14 days
15279762Ferrari Clamp - 279762$0.98Special order, ships in 7-14 days
16217854Ferrari CLAMP - 217854$0.52Available, ships in 3-6 days
17898656Ferrari Cable Grommet - 898656$6.10Special order, ships in 7-14 days
1886844300Ferrari LH Waterproof Membrane - 86844300$93.53Special order, ships in 7-14 days
1886844400Ferrari RH Waterproof Membrane - 86844400$93.53Special order, ships in 7-14 days
1913832101Ferrari Flanged Nut M6 - 13832101$0.27Available, ships in 3-6 days
2085133400Ferrari Screw TSEI M8 x 20 - 85133400$1.30Available, ships in 3-6 days
2185052500Ferrari Door Lock Striker Plate - 85052500$29.48Special order, ships in 7-14 days
2285052600Ferrari Door Striker Plate Shim - 85052600$11.56Special order, ships in 7-14 days
2382936400Ferrari Sheath - 82936400$8.59Special order, ships in 7-14 days
2469877100Ferrari Door Bowden Cable - 69877100$68.83Special order, ships in 7-14 days
25291408Ferrari Clip - 291408$0.34Special order, ships in 7-14 days
26248061Ferrari Clip - 248061$4.12Available, ships in 3-6 days
2769708300Ferrari Clip - 69708300$2.59Available, ships in 3-6 days
2881486000Ferrari Door Arrester Tie-Rod - 81486000$91.08Available, ships in 3-6 days
2981916500Ferrari Door Safety Hook Cap - 81916500$9.08Special order, ships in 7-14 days
3086690400Ferrari Latch Holder LHD - 86690400$295.43Special order, ships in 7-14 days
3086985800Ferrari Latch Holder RHD - 86985800$295.43Special order, ships in 7-14 days
