Ferrari F8 Spider — [VEHICLE TRIM] - E.39 - REAR LID OPENING MECHANISM (diagram 0140)
Exploded view of the [vehicle trim] - e.39 - rear lid opening mechanism on the Ferrari F8 Spider, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [VEHICLE TRIM] - E.39 - REAR LID OPENING MECHANISM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0140.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 65808100 | Ferrari Bonnet Handle Complete - 65808100 | Superseded | Order 80176200 instead | |
| 11087675 | Ferrari Circlip - 11087675 | Superseded | Order 11087676 instead | |
| 248061 | Ferrari Clip - 248061 | $4.12 | Available, ships in 3-6 days | |
| 20035903 | Ferrari Door Lock Circlips - 20035903 | Superseded | Order 11087676 instead | |
| 1 | 87513800 | Ferrari Rear Lid Handle With Cable Complete LHD - 87513800 | $369.30 | Special order, ships in 7-14 days |
| 1 | 87258800 | Ferrari Rear Lid Handle With Cable Complete RHD - 87258800 | $344.69 | Special order, ships in 7-14 days |
| 2 | 80176200 | Ferrari Bonnet Handle Complete - 80176200 | $162.48 | Special order, ships in 7-14 days |
| 3 | 14569480 | Ferrari Clip 10x3.8 Black - 14569480 | $0.54 | Available, ships in 3-6 days |
| 4 | 14506787 | Ferrari Rubber Plug D20 - 14506787 | $10.25 | Available, ships in 3-6 days |
| 5 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 6 | 67161800 | Ferrari Anti Vibration Pad - 67161800 | $56.60 | In stock |
| 7 | 11087676 | Ferrari Circlip - 11087676 | $0.27 | Available, ships in 3-6 days |
