Ferrari F8 Spider — [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS (diagram 0157)

Exploded view of the [vehicle trim] - e.47.09 - dashboard - fasteners on the Ferrari F8 Spider, with 64 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari F8 Spider [VEHICLE TRIM] - E.47.09 - DASHBOARD - FASTENERS exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
81911200Ferrari Screw - 81911200SupersededOrder 85692200 instead
290589Ferrari Screw 4x8 - 290589SupersededOrder 309629 instead
68176300Ferrari Screw 5x12 - 68176300SupersededOrder 85692200 instead
11566224Ferrari Screw 5x14 - 11566224$0.77Available, ships in 3-6 days
65071900Ferrari Screw 6x40 - 65071900SupersededOrder 87627200 instead
13579001Ferrari Washer D.4.15-9X0.5 - 13579001SupersededOrder 12642821 instead
13337547Ferrari Washer D.5 - 13337547SupersededOrder 12642821 instead
185692000Ferrari SCREW - 85692000$0.65Available, ships in 3-6 days
284018500Ferrari Screw M10 x 75 - 84018500$10.02Special order, ships in 7-14 days
312626221Ferrari Washer - 12626221SupersededOrder 12626224 instead
312626224Ferrari Washer - 12626224$0.38Available, ships in 3-6 days
484030800Ferrari Screw - 84030800$3.91Special order, ships in 7-14 days
515213834Ferrari Screw - 15213834$2.82Available, ships in 3-6 days
612625221Ferrari Washer - 12625221$0.17Available, ships in 3-6 days
612625224Ferrari Washer - 12625224$0.13Available, ships in 3-6 days
716286124Ferrari Screw M6x20 - 16286124$0.71Special order, ships in 7-14 days
814418924Ferrari Screw M4 x 8 TCEI - 14418924$1.04Available, ships in 3-6 days
913506624Ferrari Washer - 13506624$1.25Special order, ships in 7-14 days
1010794011Ferrari Nut M4 x 0.7mm - 10794011$0.06Available, ships in 3-6 days
1111625524Ferrari Screw - 11625524$1.53Special order, ships in 7-14 days
1265752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
13309629Ferrari Screw 4x8 - 309629$4.77Special order, ships in 7-14 days
1415782504Ferrari Screw 3.5x10 - 15782504$0.86Available, ships in 3-6 days
1513577701Ferrari Washer 5.15 - 15 x 1.2 - 13577701$0.19Available, ships in 3-6 days
1685833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
1768700200Ferrari Fixing Clip - 68700200$10.68Special order, ships in 7-14 days
1814305324Ferrari Screw M6 x 20mm - 14305324$0.17Available, ships in 3-6 days
1912643701Ferrari Flat Washer - 12643701$0.12Available, ships in 3-6 days
2064830600Ferrari Screw M6 x 22 TBEI - 64830600$3.26Available, ships in 3-6 days
2168002000Ferrari Rubber Pad - 68002000$7.40Special order, ships in 7-14 days
2214059121Ferrari Nut M5 - 14059121$0.31Available, ships in 3-6 days
2315689201Ferrari Screw M3.5 x 25 - 15689201$1.92Available, ships in 3-6 days
24105864Ferrari Spacer Washer D. 6.5-24 X 1.5 - 105864$2.82Available, ships in 3-6 days
2514305924Ferrari Allen Screw 6x45 - 14305924$0.38Available, ships in 3-6 days
25231624Ferrari Allen Screw M6 x 45 - 231624SupersededOrder 14305924 instead
2612644401Ferrari Washer - 12644401$0.08Available, ships in 3-6 days
2781045300Ferrari Screw 6x16 - 81045300$1.36Special order, ships in 7-14 days
2885692300Ferrari Screw M5 x 20 TBFTX - 85692300$0.65Available, ships in 3-6 days
2987627200Ferrari Screw TBEI M6x40 - 87627200$1.42Special order, ships in 7-14 days
3012646624Ferrari Washer 6.15-15x1.5 - 12646624$0.40Available, ships in 3-6 days
31179309Ferrari ADHESIVE FOAM - 179309$8.28Available, ships in 3-6 days
32829212Ferrari Clip - 829212$9.62Special order, ships in 7-14 days
3363343400Ferrari Screw 4x15 - 63343400$5.02Available, ships in 3-6 days
3315688801Ferrari Screw M3.5 x 13 - 15688801SupersededOrder 63343400 instead
3416083401Ferrari Screw - 16083401$1.17Available, ships in 3-6 days
3614302924Ferrari Screw - 14302924$0.44Available, ships in 3-6 days
3688822200Ferrari Screw 4 x 10 - 88822200$1.30Special order, ships in 7-14 days
3713577778Ferrari Washer - 13577778$0.57Special order, ships in 7-14 days
3811625824Ferrari Screw 6x18 - 11625824$0.71Available, ships in 3-6 days
3911626124Ferrari Screw 6x25 - 11626124SupersededOrder 11612826 instead
4012642821Ferrari Washer D. 4.15 - 12 x 1.x - 12642821$0.82Available, ships in 3-6 days
4110979424Ferrari Screw - 10979424$0.19Available, ships in 3-6 days
4212647878Ferrari Washer - 12647878$5.65Special order, ships in 7-14 days
4314418131Ferrari Screw M3 x 10 TCEI - 14418131$0.38Available, ships in 3-6 days
4414496101Ferrari Washer - 14496101$0.12Available, ships in 3-6 days
45267559Ferrari Screw M5 x 19 TPEI - 267559$12.23Available, ships in 3-6 days
4686839000Ferrari Rubber Washer - 86839000$2.13Special order, ships in 7-14 days
4785833700Ferrari SCREW - 85833700$0.65Available, ships in 3-6 days
4867278400Ferrari BRACKET - 67278400$21.60Special order, ships in 7-14 days
4985692200Ferrari SCREW M5 x 12 - 85692200$0.65Available, ships in 3-6 days
5014189071Ferrari M6 x 1Screw clip - 14189071$1.36Available, ships in 3-6 days
5111625714Ferrari SCREW - 11625714$1.02Special order, ships in 7-14 days
5285834000Ferrari Screw M5 x 25 - 85834000$0.71Special order, ships in 7-14 days
5587511200Ferrari Screw - 87511200$0.79Special order, ships in 7-14 days
