Ferrari F8 Spider — [ELECTRICAL SYSTEM] - F.8 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM (diagram 0183)
Exploded view of the [electrical system] - f.8 - various fastenings for the electrical system on the Ferrari F8 Spider, with 52 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Spider [ELECTRICAL SYSTEM] - F.8 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-spider/0183.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 306631 | Ferrari Clip - 306631 | $7.59 | Special order, ships in 7-14 days | |
| 13046011 | Ferrari Flanged Nut - 13046011 | $0.73 | Available, ships in 3-6 days | |
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 10615301 | Ferrari Washer - 10615301 | Superseded | Order 149951 instead | |
| 13579001 | Ferrari Washer D.4.15-9X0.5 - 13579001 | Superseded | Order 12642821 instead | |
| 13337547 | Ferrari Washer D.5 - 13337547 | Superseded | Order 12642821 instead | |
| 1 | 254078 | Ferrari Clip - 254078 | $3.68 | Special order, ships in 7-14 days |
| 2 | 242384 | Ferrari Clip - 242384 | $0.59 | Available, ships in 3-6 days |
| 3 | 277002 | Ferrari Bracket LHD - 277002 | $64.00 | Special order, ships in 7-14 days |
| 4 | 306756 | Ferrari Clip - 306756 | $1.59 | Special order, ships in 7-14 days |
| 5 | 16281827 | Ferrari Screw 5x14 - 16281827 | $0.46 | Special order, ships in 7-14 days |
| 6 | 85692300 | Ferrari Screw M5 x 20 TBFTX - 85692300 | $0.65 | Available, ships in 3-6 days |
| 7 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 8 | 866955 | Ferrari Complete Front Mounting Bracket for SCM - 866955 | $59.07 | Special order, ships in 7-14 days |
| 8 | 896553 | Ferrari Complete Front Mounting Bracket for SCM - 896553 | $76.30 | Special order, ships in 7-14 days |
| 9 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 10 | 16286127 | Ferrari Screw 6x20 - 16286127 | $0.82 | Available, ships in 3-6 days |
| 11 | 263561 | Ferrari Sponge - 263561 | $2.11 | Special order, ships in 7-14 days |
| 12 | 260064 | Ferrari Ring Clamp - 260064 | Superseded | Order 808986 instead |
| 12 | 808986 | Ferrari Ring Clamp - 808986 | $0.44 | Special order, ships in 7-14 days |
| 13 | 12642821 | Ferrari Washer D. 4.15 - 12 x 1.x - 12642821 | $0.82 | Available, ships in 3-6 days |
| 14 | 65752800 | Ferrari Screw M4 x 10 TBEI - 65752800 | $4.12 | Available, ships in 3-6 days |
| 15 | 303339 | Ferrari Long Shank Clip - 303339 | $0.59 | Special order, ships in 7-14 days |
| 16 | 179309 | Ferrari ADHESIVE FOAM - 179309 | $8.28 | Available, ships in 3-6 days |
| 17 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 17 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 18 | 14040514 | Ferrari Flanged Nut - 14040514 | Superseded | Order 13046011 instead |
| 19 | 282796 | Ferrari LH Bracket - 282796 | $20.66 | Special order, ships in 7-14 days |
| 19 | 282795 | Ferrari RH Bracket - 282795 | $20.66 | Special order, ships in 7-14 days |
| 20 | 231620 | Ferrari/Maserati Screw - 231620 | $0.58 | In stock |
| 21 | 11673111 | Ferrari Nut - 11673111 | $0.52 | Available, ships in 3-6 days |
| 21 | 14084111 | Ferrari Nut - 14084111 | Superseded | Order 11673111 instead |
| 22 | 149951 | Ferrari Shake Proof Washer - 149951 | $0.59 | Available, ships in 3-6 days |
| 23 | 303365 | Ferrari Clip - 303365 | $2.61 | Available, ships in 3-6 days |
| 24 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
| 25 | 284622 | Ferrari Clip - 284622 | $3.47 | Special order, ships in 7-14 days |
| 26 | 317027 | Ferrari Clip - 317027 | $1.02 | Special order, ships in 7-14 days |
| 27 | 16285127 | Ferrari Screw M5 x 16 - 16285127 | $1.05 | Special order, ships in 7-14 days |
| 28 | 318547 | Ferrari Ring Clamp - 318547 | $3.70 | Special order, ships in 7-14 days |
| 29 | 10441990 | Ferrari P Clip Bracket With Sheath - 10441990 | $1.42 | Available, ships in 3-6 days |
| 30 | 178772 | Ferrari Stud - 178772 | $16.45 | Special order, ships in 7-14 days |
| 31 | 11625624 | Ferrari/Maserati Screw - 11625624 | $1.50 | In stock |
| 32 | 212519 | Ferrari Stud Bolt - 212519 | $12.29 | Special order, ships in 7-14 days |
| 33 | 11625824 | Ferrari Screw 6x18 - 11625824 | $0.71 | Available, ships in 3-6 days |
| 34 | 10815787 | Ferrari Clamp - 10815787 | $0.31 | Available, ships in 3-6 days |
| 35 | 14569880 | Ferrari Clip 14.5x3 - 14569880 | $0.65 | Special order, ships in 7-14 days |
| 36 | 312615 | Ferrari Tank Wiring Harness Protection Bracket - 312615 | $22.87 | Special order, ships in 7-14 days |
| 39 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
| 40 | 289133 | Ferrari Clip - 289133 | $3.47 | Special order, ships in 7-14 days |
