Ferrari F8 Tributo — [ENGINE] - B.01 - CRANKCASE (diagram 0004)

Exploded view of the [engine] - b.01 - crankcase on the Ferrari F8 Tributo, with 53 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari F8 Tributo [ENGINE] - B.01 - CRANKCASE exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
302154Ferrari Cap - 302154$13.03Special order, ships in 7-14 days
296397Ferrari Gasket - 296397SupersededOrder 339289 instead
310839Ferrari Gasket - 310839SupersededOrder 339287 instead
300499Ferrari Screw - 300499$1.44Special order, ships in 7-14 days
216568Ferrari Screw 6x30 - 216568SupersededOrder 231621 instead
11066875Ferrari Snap Ring - 11066875SupersededOrder 11066876 instead
194490Ferrari Threaded Plug - 194490SupersededOrder 164400 instead
194495Ferrari Threaded Plug - 194495SupersededOrder 282755 instead
14326001Ferrari Threaded Plug D 10x1.25 - 14326001SupersededOrder 282755 instead
11197779Ferrari Washer - 11197779SupersededOrder 11197774 instead
1820170Ferrari Assemblato Basamento - Sotto - 820170$7,589.22Special order, ships in 7-14 days
2312059Ferrari Alignment Dowel - 312059$2.61Special order, ships in 7-14 days
3270465Ferrari Stud Bolt - 270465$36.92Special order, ships in 7-14 days
4270466Ferrari Stud Bolt - 270466$41.82Special order, ships in 7-14 days
5133988Ferrari Plain Nut M10 x 1.25 x 8 - 133988$0.38Available, ships in 3-6 days
6178348Ferrari Washer - 178348$1.40Available, ships in 3-6 days
7134705Ferrari O-Ring - 134705$0.76In stock
8312836Ferrari Complete Valve Holder - 312836$492.43Special order, ships in 7-14 days
911197774Ferrari Conic Washer 6.4x12x1.2 - 11197774$0.12Available, ships in 3-6 days
1013026924Ferrari Screw 6x14 - 13026924$0.57Available, ships in 3-6 days
11103994Ferrari Gasket - 103994$9.33Special order, ships in 7-14 days
12339289Ferrari Gasket - 339289$81.23Special order, ships in 7-14 days
13231620Ferrari/Maserati Screw - 231620$0.58In stock
14317217Ferrari Chain Cooling Nozzle Assembly - 317217$91.08Special order, ships in 7-14 days
15282392Ferrari Screw 6x14 - 282392$0.96Available, ships in 3-6 days
1611066876Ferrari Circlip 20E - 11066876$0.13Available, ships in 3-6 days
17247049Ferrari Bearing - 247049$87.40Special order, ships in 7-14 days
1811060276Ferrari Circlip - 11060276$0.92Available, ships in 3-6 days
19304697Ferrari Drive Joint - 304697$295.43Special order, ships in 7-14 days
20231618Ferrari Allen Head Screw M6x20 TCEI - 231618$0.57Available, ships in 3-6 days
21164400Ferrari Threaded Plug - 164400$6.96Special order, ships in 7-14 days
22306145Ferrari 488 Crankcase Drain Plug - 306145$11.99In stock
2310259960Ferrari Copper Washer - 10259960$1.21In stock
24315493Ferrari Screw - 315493$2.13Special order, ships in 7-14 days
25307477Ferrari/Maserati Crankcase Threaded Plug - 307477$5.35In stock
2610263460Ferrari/Maserati Copper Washer - 10263460$1.93In stock
27282755Ferrari Threaded Plug D 10x1.25 - 282755$4.35Available, ships in 3-6 days
28935026Ferrari Ugello Raffreddam. Catena C - 935026$120.62Special order, ships in 7-14 days
29291078Ferrari Threaded Plug 12x11 - 291078$5.02Special order, ships in 7-14 days
30311001Ferrari Alignment Dowel - 311001$6.10Special order, ships in 7-14 days
31935031Ferrari Ugello Raffreddam. Catena C - 935031$120.62Special order, ships in 7-14 days
32334895Ferrari Gasket - 334895$7.36Special order, ships in 7-14 days
33334890Ferrari Cylinder Sleeve - 334890$545.77Special order, ships in 7-14 days
34278120Ferrari Stud Bolt - 278120$39.37Special order, ships in 7-14 days
35298858Ferrari Piston Cooling Nozzle Assembly - 298858$64.00Special order, ships in 7-14 days
36298859Ferrari Piston Cooling Nozzle Assembly - 298859$44.29Special order, ships in 7-14 days
37271598Ferrari/Maserati Front Crankshaft Oil Seal - 271598$62.78In stock
38339287Ferrari Gasket - 339287$44.29Special order, ships in 7-14 days
39270464Ferrari Stud Bolt - 270464$46.75Special order, ships in 7-14 days
40185360Ferrari Centering Dowel - 185360$5.44Special order, ships in 7-14 days
41271564Ferrari Stud Bolt M14 x 1.5 to M12 - 271564$46.75Available, ships in 3-6 days
42282753Ferrari Cover - Threaded Plug - 282753$13.09Special order, ships in 7-14 days
43231621Ferrari Allen Screw M6 x 30 TCEI - 231621$0.73Available, ships in 3-6 days
