Ferrari F8 Tributo — [ENGINE] - B.33 - ALTERNATOR DRIVE (diagram 0038)
Exploded view of the [engine] - b.33 - alternator drive on the Ferrari F8 Tributo, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [ENGINE] - B.33 - ALTERNATOR DRIVE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0038.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 281995 | Ferrari/Maserati Serpentine Belt Tensioner Assembly - 281995 | $849.55 | In stock |
| 2 | 238590 | Ferrari/Maserati Belt Pulley - 238590 | $66.38 | In stock |
| 3 | 269781 | Ferrari Bushing - 269781 | $12.78 | Special order, ships in 7-14 days |
| 4 | 305554 | Ferrari Screw M10 x 1.5 x 40 - 305554 | $2.61 | Special order, ships in 7-14 days |
| 5 | 12642524 | Ferrari Washer - 12642524 | $0.40 | Available, ships in 3-6 days |
| 6 | 291236 | Ferrari Accessory Drive Belt - 291236 | $80.25 | In stock |
