Ferrari F8 Tributo — [GEARBOX] - C.02 - EXTERNAL GEARBOX CONTROLS (diagram 0042)
Exploded view of the [gearbox] - c.02 - external gearbox controls on the Ferrari F8 Tributo, with 4 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [GEARBOX] - C.02 - EXTERNAL GEARBOX CONTROLS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0042.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 252661 | Ferrari Release Arm Mounting Bracket - 252661 | $124.81 | Special order, ships in 7-14 days | |
| 1 | 238370 | Ferrari Release Lever Complete - 238370 | $108.16 | Special order, ships in 7-14 days |
| 2 | 11066176 | Ferrari Seeger Ring D.13 - 11066176 | $0.08 | Available, ships in 3-6 days |
| 3 | 310524 | Ferrari Release Arm Mounting Bracket - 310524 | $127.82 | Special order, ships in 7-14 days |
