Ferrari F8 Tributo — [MECHANICAL SYSTEM] - D.30.02 - STEERING WHEEL AND STEERING SYSTEM - STEERING WHEEL AND AIRBAG (diagram 0085)
Exploded view of the [mechanical system] - d.30.02 - steering wheel and steering system - steering wheel and airbag on the Ferrari F8 Tributo, with 30 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [MECHANICAL SYSTEM] - D.30.02 - STEERING WHEEL AND STEERING SYSTEM - STEERING WHEEL AND AIRBAG exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0085.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 275398 | Ferrari Screw - 275398 | Superseded | Order 301723 instead | |
| 1 | 881217 | Ferrari Gruppo Com.Cambio F1 Racing - 881217 | $5,926.88 | Special order, ships in 7-14 days |
| 1 | 890896 | Ferrari Gruppo Com.Cambio F1 Racing - 890896 | $6,388.21 | Special order, ships in 7-14 days |
| 1 | 892382 | Ferrari Gruppo Comandi F1 Keyless - 892382 | $4,884.63 | Special order, ships in 7-14 days |
| 1 | 70007277 | Ferrari Off-Catalogue Shift Paddle A - 70007277 | $39,923.43 | Contact us to order |
| 1 | 327250 | Ferrari Shift Paddle Assembly - 327250 | $2,777.27 | Special order, ships in 7-14 days |
| 1 | 327251 | Ferrari Shift Paddle Assembly - 327251 | $4,552.30 | Special order, ships in 7-14 days |
| 2 | 309296 | Ferrari Steering Angle Sensor - 309296 | $371.53 | Special order, ships in 7-14 days |
| 3 | 327252 | Ferrari Clock Spring Contact - 327252 | $811.38 | Special order, ships in 7-14 days |
| 4 | 70007182 | Ferrari Compl. F142Mfl Carbon Steeri - 70007182 | $56,843.54 | Contact us to order |
| 4 | 860652 | Ferrari Volante Cpl F142Mfl Alcantar - 860652 | Price on request | Contact us for price and availability |
| 4 | 860656 | Ferrari Volante Cpl F142Mfl Base Pel - 860656 | $12,670.08 | Contact us to order |
| 4 | 892422 | Ferrari Volante Cpl F142Mfl Carb Opa - 892422 | $20,839.42 | Contact us to order |
| 4 | 860622 | Ferrari Volante Cpl F142Mfl Carb+Led - 860622 | $19,998.64 | Contact us to order |
| 5 | 321865 | Ferrari RH Nit Thumbwheel Control - 321865 | $565.49 | Special order, ships in 7-14 days |
| 6 | 321866 | Ferrari LH Nit Thumbwheel Control - 321866 | $565.49 | Special order, ships in 7-14 days |
| 7 | 14506587 | Ferrari Rubber Grommet - 14506587 | $0.38 | Available, ships in 3-6 days |
| 8 | 301723 | Ferrari Screw - 301723 | $164.72 | Special order, ships in 7-14 days |
| 10 | 879116 | Ferrari Nodo Volante F142Mfl Base - 879116 | $7,194.47 | Special order, ships in 7-14 days |
| 10 | 879114 | Ferrari Nodo Volante F142Mfl Carb. - 879114 | $9,645.01 | Special order, ships in 7-14 days |
| 10 | 892424 | Ferrari Nodo Volante F142Mfl Carb. - 892424 | $9,441.01 | Special order, ships in 7-14 days |
| 10 | 70007191 | Ferrari Steering Wheel Node - 70007191 | $46,021.88 | Contact us to order |
| 11 | 828380 | Ferrari Clock Spring Connector Spring - 828380 | $3.26 | Available, ships in 3-6 days |
| 12 | 828381 | Ferrari Clock Spring Connector Lock - 828381 | $12.21 | Available, ships in 3-6 days |
| 13 | 70006274 | Ferrari Cicm Off-Catalogue Shift Pad - 70006274 | $8,750.24 | Special order, ships in 7-14 days |
| 13 | 70006275 | Ferrari Cicm Off-Catalogue Shift Pad - 70006275 | $9,333.07 | Special order, ships in 7-14 days |
| 13 | 70006497 | Ferrari Off-Catalogue Carbon Shift P - 70006497 | $12,301.86 | Contact us to order |
| 13 | 70006495 | Ferrari Off-Catalogue Gloss Carbon S - 70006495 | $11,047.72 | Contact us to order |
| 14 | 856950 | Ferrari Vetrino Barra A Led Volante - 856950 | $344.21 | Special order, ships in 7-14 days |
| 15 | 331008 | Ferrari Barra Led - 331008 | $1,155.62 | Special order, ships in 7-14 days |
