Ferrari F8 Tributo — [VEHICLE TRIM] - E.09 - FRONT LID SUBSTRUCTURE (diagram 0105)
Exploded view of the [vehicle trim] - e.09 - front lid substructure on the Ferrari F8 Tributo, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [VEHICLE TRIM] - E.09 - FRONT LID SUBSTRUCTURE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0105.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 985850394 | Ferrari Compl. Front Lid Skin And Su - 985850394 | $18,164.74 | Contact us to order |
| 1 | 985880997 | Ferrari Compl. Front Lid Skin And Su - 985880997 | $14,964.29 | Contact us to order |
| 2 | 84633000 | Ferrari RH Hinge Complete - 84633000 | $216.66 | Special order, ships in 7-14 days |
| 3 | 84632900 | Ferrari LH Hinge Complete - 84632900 | $216.66 | Special order, ships in 7-14 days |
| 4 | 16287124 | Ferrari Flanged Bolt - 16287124 | $2.38 | Available, ships in 3-6 days |
| 5 | 13578301 | Ferrari Washer - 13578301 | $0.17 | Special order, ships in 7-14 days |
| 6 | 14059311 | Ferrari NUT - 14059311 | $0.52 | Available, ships in 3-6 days |
