Ferrari F8 Tributo — [VEHICLE TRIM] - E.10 - REAR LID SUBSTRUCTURE (diagram 0106)
Exploded view of the [vehicle trim] - e.10 - rear lid substructure on the Ferrari F8 Tributo, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [VEHICLE TRIM] - E.10 - REAR LID SUBSTRUCTURE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0106.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 985874512 | Ferrari Cofano Post. Lastrato Cpl Pr - 985874512 | $3,622.17 | Special order, ships in 7-14 days |
| 1 | 855145 | Ferrari Compl. Rear Lid - 855145 | $14,546.75 | Contact us to order |
| 2 | 81429200 | Ferrari RH Engine Compartment Lid - 81429200 | $465.04 | Special order, ships in 7-14 days |
| 3 | 81429300 | Ferrari LH Engine Compartment Lid - 81429300 | $465.04 | Special order, ships in 7-14 days |
| 4 | 81905000 | Ferrari Shim 1mm - 81905000 | $6.98 | Special order, ships in 7-14 days |
| 5 | 82119700 | Ferrari Shim 3mm - 82119700 | $8.51 | Special order, ships in 7-14 days |
| 6 | 16043734 | Ferrari Screw - 16043734 | $5.19 | Special order, ships in 7-14 days |
| 7 | 12642001 | Ferrari Washer - 12642001 | $0.27 | Available, ships in 3-6 days |
| 8 | 13046224 | Ferrari Nut - 13046224 | $0.73 | Available, ships in 3-6 days |
