Ferrari F8 Tributo — [VEHICLE TRIM] - E.25 - WINDSCREEN (diagram 0124)
Exploded view of the [vehicle trim] - e.25 - windscreen on the Ferrari F8 Tributo, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [VEHICLE TRIM] - E.25 - WINDSCREEN exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0124.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 768291 | Ferrari Compl. Windscreen - 768291 | $4,040.75 | Contact us to order |
| 1 | 938935 | Ferrari Parabrezza Base Cpl - 938935 | Superseded | Order 768291 instead |
| 1 | 768299 | Ferrari Parabrezza Termoisolante Cpl - 768299 | $6,991.54 | Contact us to order |
| 1 | 938936 | Ferrari Parabrezza Termoisolante Cpl - 938936 | Superseded | Order 768299 instead |
| 2 | 82234900 | Ferrari Spacer Block - 82234900 | $4.41 | Available, ships in 3-6 days |
| 3 | 179309 | Ferrari ADHESIVE FOAM - 179309 | $8.28 | Available, ships in 3-6 days |
