Ferrari F8 Tributo — [VEHICLE TRIM] - E.37 - REAR LID LOCK (diagram 0138)
Exploded view of the [vehicle trim] - e.37 - rear lid lock on the Ferrari F8 Tributo, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [VEHICLE TRIM] - E.37 - REAR LID LOCK exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0138.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 84076100 | Ferrari Engine Compartment Lid Lock - 84076100 | $216.66 | Special order, ships in 7-14 days |
| 2 | 14569680 | Ferrari Clip - 14569680 | $0.13 | Special order, ships in 7-14 days |
| 3 | 12647604 | Ferrari Washer - 12647604 | $0.12 | Available, ships in 3-6 days |
| 4 | 14059214 | Ferrari Flanged Nut M6 - 14059214 | $0.38 | Available, ships in 3-6 days |
| 5 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 6 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
