Ferrari F8 Tributo — [VEHICLE TRIM] - E.58 - BADGES (diagram 0171)
Exploded view of the [vehicle trim] - e.58 - badges on the Ferrari F8 Tributo, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [VEHICLE TRIM] - E.58 - BADGES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0171.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 70004391 | Ferrari Mask For Airbrushed Horse Lo - 70004391 | $313.28 | Special order, ships in 7-14 days |
| 1 | 86921300 | Ferrari Squadra Corse Shield Badge - 86921300 | Superseded | Order 973211 instead |
| 1 | 973211 | Ferrari Squadra Corse Shield Badge - 973211 | $1,600.44 | Special order, ships in 7-14 days |
| 2 | 16101711 | Ferrari Nut M3 x 2.4 - 16101711 | $0.17 | Available, ships in 3-6 days |
| 3 | 12642878 | Ferrari Washer - 12642878 | $0.19 | Available, ships in 3-6 days |
| 4 | 878453 | Ferrari Dashboard Badge F142Nb - 878453 | $342.66 | Special order, ships in 7-14 days |
| 5 | 70006277 | Ferrari Badge - 70006277 | $125.37 | Special order, ships in 7-14 days |
| 5 | 63482200 | Ferrari Rear Emblem / Motif - 63482200 | $114.05 | In stock |
| 6 | 84706300 | Ferrari Italian Flag Badge - 84706300 | Superseded | Order 988640 instead |
| 6 | 988640 | Ferrari Italian Flag Badge - 988640 | $835.97 | Available, ships in 3-6 days |
