Ferrari F8 Tributo — [ELECTRICAL SYSTEM] - F.04 - OTHER ELECTRICAL CONTROLS (diagram 0179)
Exploded view of the [electrical system] - f.04 - other electrical controls on the Ferrari F8 Tributo, with 29 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [ELECTRICAL SYSTEM] - F.04 - OTHER ELECTRICAL CONTROLS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0179.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 188253 | Ferrari Bicolor Warning Light - 188253 | Superseded | Order 239744 instead | |
| 14303324 | Ferrari/Maserati Screw - 14303324 | $0.29 | In stock | |
| 1 | 319573 | Ferrari Nit Control - 319573 | $1,696.56 | Special order, ships in 7-14 days |
| 1 | 331197 | Ferrari Nit Control - 331197 | $1,696.56 | Special order, ships in 7-14 days |
| 2 | 319570 | Ferrari Tft Control - 319570 | $1,112.24 | Available, ships in 3-6 days |
| 2 | 331194 | Ferrari Tft Control - 331194 | $1,327.73 | Special order, ships in 7-14 days |
| 2 | 815314 | Ferrari Tft Control - 815314 | $1,401.51 | Special order, ships in 7-14 days |
| 2 | 815323 | Ferrari Tft Control - 815323 | $1,401.51 | Special order, ships in 7-14 days |
| 3 | 239744 | Ferrari Two-Tone Infoled - 239744 | $193.35 | Special order, ships in 7-14 days |
| 3 | 847648 | Ferrari Two-Tone Infoled - 847648 | $194.22 | Special order, ships in 7-14 days |
| 4 | 330892 | Ferrari Lights And Rear Fog Light Sw - 330892 | $860.56 | Special order, ships in 7-14 days |
| 5 | 15782504 | Ferrari Screw 3.5x10 - 15782504 | $0.86 | Available, ships in 3-6 days |
| 6 | 319555 | Ferrari EPB Switch With Autopark Disable - 319555 | $417.97 | Special order, ships in 7-14 days |
| 7 | 65752800 | Ferrari Screw M4 x 10 TBEI - 65752800 | $4.12 | Available, ships in 3-6 days |
| 8 | 193862 | Ferrari Steering Column Adjustment Control - 193862 | $93.17 | Available, ships in 3-6 days |
| 9 | 319063 | Ferrari Door Mirror Control - 319063 | $416.09 | Special order, ships in 7-14 days |
| 9 | 319552 | Ferrari Rear View Mirror Control - 319552 | $467.15 | Special order, ships in 7-14 days |
| 10 | 16082801 | Ferrari Screw - 16082801 | $0.06 | Special order, ships in 7-14 days |
| 11 | 903655 | Ferrari Plancetta Clima Ac F142M Fl - 903655 | $1,849.95 | Special order, ships in 7-14 days |
| 12 | 910716 | Ferrari Luggage Compartment/Fuel Filler Flap Release Control - 910716 | $295.43 | Special order, ships in 7-14 days |
| 13 | 910712 | Ferrari Comando Memorie Sedili Setto - 910712 | $566.30 | Special order, ships in 7-14 days |
| 14 | 163675 | Ferrari Inertia Switch - 163675 | $39.46 | Available, ships in 3-6 days |
| 15 | 16285127 | Ferrari Screw M5 x 16 - 16285127 | $1.05 | Special order, ships in 7-14 days |
| 16 | 188266 | Ferrari GLOVE COMPARTMENT LIGHT BUTTON - 188266 | $49.14 | Special order, ships in 7-14 days |
| 17 | 215406 | Ferrari 12V Socket - 215406 | $71.28 | Available, ships in 3-6 days |
| 18 | 183270 | Ferrari Cigarette Lighter - 183270 | Superseded | Order 804743 instead |
| 18 | 804743 | Ferrari Cigarette Lighter - 804743 | $56.52 | Available, ships in 3-6 days |
| 19 | 183271 | Ferrari Cigarette Lighter Casing - 183271 | $58.98 | Special order, ships in 7-14 days |
| 20 | 14303224 | Ferrari Screw 4x16 - 14303224 | $1.15 | Special order, ships in 7-14 days |
