Ferrari F8 Tributo — [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM (diagram 0183)
Exploded view of the [electrical system] - f.08 - various fastenings for the electrical system on the Ferrari F8 Tributo, with 38 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F8 Tributo [ELECTRICAL SYSTEM] - F.08 - VARIOUS FASTENINGS FOR THE ELECTRICAL SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f8-tributo/0183.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 306631 | Ferrari Clip - 306631 | $7.59 | Special order, ships in 7-14 days | |
| 14569480 | Ferrari Clip 10x3.8 Black - 14569480 | $0.54 | Available, ships in 3-6 days | |
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 13579001 | Ferrari Washer D.4.15-9X0.5 - 13579001 | Superseded | Order 12642821 instead | |
| 13337547 | Ferrari Washer D.5 - 13337547 | Superseded | Order 12642821 instead | |
| 1 | 866955 | Ferrari Complete Front Mounting Bracket for SCM - 866955 | $59.07 | Special order, ships in 7-14 days |
| 1 | 896553 | Ferrari Complete Front Mounting Bracket for SCM - 896553 | $76.30 | Special order, ships in 7-14 days |
| 2 | 16281827 | Ferrari Screw 5x14 - 16281827 | $0.46 | Special order, ships in 7-14 days |
| 3 | 217854 | Ferrari CLAMP - 217854 | $0.52 | Available, ships in 3-6 days |
| 4 | 16286127 | Ferrari Screw 6x20 - 16286127 | $0.82 | Available, ships in 3-6 days |
| 5 | 81045300 | Ferrari Screw 6x16 - 81045300 | $1.36 | Special order, ships in 7-14 days |
| 6 | 11625524 | Ferrari Screw - 11625524 | $1.53 | Special order, ships in 7-14 days |
| 7 | 12642821 | Ferrari Washer D. 4.15 - 12 x 1.x - 12642821 | $0.82 | Available, ships in 3-6 days |
| 8 | 254078 | Ferrari Clip - 254078 | $3.68 | Special order, ships in 7-14 days |
| 9 | 306756 | Ferrari Clip - 306756 | $1.59 | Special order, ships in 7-14 days |
| 10 | 303339 | Ferrari Long Shank Clip - 303339 | $0.59 | Special order, ships in 7-14 days |
| 11 | 145854 | Ferrari Cable tie 200mm - 145854 | $0.57 | Available, ships in 3-6 days |
| 12 | 325313 | Ferrari Clip - 325313 | $2.59 | Special order, ships in 7-14 days |
| 13 | 82889700 | Ferrari Clip - 82889700 | $1.63 | Available, ships in 3-6 days |
| 14 | 318547 | Ferrari Ring Clamp - 318547 | $3.70 | Special order, ships in 7-14 days |
| 15 | 277002 | Ferrari Bracket LHD - 277002 | $64.00 | Special order, ships in 7-14 days |
| 16 | 312615 | Ferrari Tank Wiring Harness Protection Bracket - 312615 | $22.87 | Special order, ships in 7-14 days |
| 17 | 806341 | Ferrari LH Turbo Override Bracket - 806341 | $110.13 | Special order, ships in 7-14 days |
| 17 | 881762 | Ferrari RH Turbo Override Bracket - 881762 | Price on request | Contact us for price and availability |
| 18 | 244223 | Ferrari Clip - 244223 | $8.93 | Special order, ships in 7-14 days |
| 19 | 179309 | Ferrari ADHESIVE FOAM - 179309 | $8.28 | Available, ships in 3-6 days |
| 20 | 263561 | Ferrari Sponge - 263561 | $2.11 | Special order, ships in 7-14 days |
| 21 | 248061 | Ferrari Clip - 248061 | $4.12 | Available, ships in 3-6 days |
| 22 | 242384 | Ferrari Clip - 242384 | $0.59 | Available, ships in 3-6 days |
| 23 | 284622 | Ferrari Clip - 284622 | $3.47 | Special order, ships in 7-14 days |
| 24 | 317027 | Ferrari Clip - 317027 | $1.02 | Special order, ships in 7-14 days |
| 25 | 11625824 | Ferrari Screw 6x18 - 11625824 | $0.71 | Available, ships in 3-6 days |
| 26 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 27 | 212519 | Ferrari Stud Bolt - 212519 | $12.29 | Special order, ships in 7-14 days |
| 29 | 10815787 | Ferrari Clamp - 10815787 | $0.31 | Available, ships in 3-6 days |
| 30 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
