Ferrari F80 — [ENGINE] - B.3 - ENGINE COVERS (diagram 0006)
Exploded view of the [engine] - b.3 - engine covers on the Ferrari F80, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ENGINE] - B.3 - ENGINE COVERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0006.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 11197779 | Ferrari Washer - 11197779 | Superseded | Order 11197774 instead | |
| 1 | 55062692 | Ferrari Pump Drive Cover - 55062692 | $13,659.68 | Special order, ships in 7-14 days |
| 2 | 825475 | Ferrari Water Delivery Pipe - 825475 | $51.62 | Special order, ships in 7-14 days |
| 3 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 4 | 255494 | Ferrari Screw - 255494 | $18.76 | Available, ships in 3-6 days |
| 5 | 180137 | Ferrari/Maserati Water Temperature Sender / Sensor - 180137 | $25.19 | In stock |
| 6 | 810696 | Ferrari Hose - 810696 | $115.54 | Special order, ships in 7-14 days |
| 7 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
| 8 | 262913 | Ferrari Thermostat/Pressure Switch - 262913 | $371.08 | In stock |
| 9 | 966229 | Ferrari SCREW - 966229 | Price on request | Contact us for price and availability |
| 10 | 226901 | Ferrari SCREW - 226901 | Price on request | Contact us for price and availability |
| 11 | 14300534 | Ferrari Allen Screw - 14300534 | $5.21 | Available, ships in 3-6 days |
| 11 | 14300524 | Ferrari Screw - 14300524 | Superseded | Order 14300534 instead |
| 12 | 11197774 | Ferrari Conic Washer 6.4x12x1.2 - 11197774 | $0.12 | Available, ships in 3-6 days |
| 13 | 14459081 | Ferrari Gasket - 14459081 | $4.77 | Special order, ships in 7-14 days |
| 14 | 14459581 | Ferrari O-Ring - 14459581 | $4.77 | Special order, ships in 7-14 days |
| 15 | 14458381 | Ferrari O-Ring - 14458381 | $2.59 | Special order, ships in 7-14 days |
